ABB PP886 3BSE092980R1 Operation Panel

I. Overview

ABB PP886 3BSE092980R1 adopts an industrial-grade rugged structure, with a body size of 215mm×320mm×55mm (width × height × thickness), suitable for 19-inch standard cabinet embedded installation or independent desktop placement. The front panel is made of Corning Gorilla Glass, with a Mohs hardness of Grade 7, featuring scratch resistance and impact resistance, and reaches an IP65 protection level, which can resist dust, moisture, and accidental collisions in industrial sites. It is equipped with a 12.1-inch XGA (1024×768) high-brightness LCD screen, with a brightness of 450cd/㎡ and a contrast ratio of 1000:1, ensuring clear display even in strong light or dim environments. It has a built-in industrial-grade Intel Core processor, paired with 4GB DDR4 memory and 64GB SSD storage, ensuring smooth operation without lag during multi-page switching and large-volume data refreshing. It operates within a temperature range of -10℃ to 60℃ and a relative humidity of 5% to 95% (non-condensing), making it compatible with complex environments such as high-humidity chemical workshops and high-temperature metallurgical plants. The Mean Time Between Failures (MTBF) is ≥80,000 hours (per Telcordia standard, at 25℃), meeting the "long-cycle, high-reliability" operation requirements of industrial systems. Meanwhile, it is highly compatible with the ABB 800xA control system and third-party PLCs (e.g., Siemens S7-1500, Rockwell ControlLogix), supporting plug-and-play and rapid configuration, which reduces the difficulty of system integration.

II. Technical Parameters

1. Display and Operation Parameters

2. Hardware and Performance Parameters

3. Software and Communication Parameters

4. Environmental and Reliability Parameters

III. Functional Characteristics

1. High-Definition Visualization and Convenient Operation

• High-Definition Full-View Display: The 12.1-inch XGA LCD screen, combined with 450cd/㎡ high brightness, ensures clear display of process flow diagrams, parameter values, and alarm information even on outdoor operation platforms under direct sunlight or in dim underground workshops. The 178° full-view design allows multiple operators to view simultaneously from different angles, avoiding operational misjudgments caused by viewing angle issues. In the reactor monitoring page of the chemical industry, real-time values and trend curves of 16 parameters can be displayed simultaneously, with the value font enlarged to 16 points to ensure clear visibility from a distance.
• Flexible Touch Control and Quick Operation: The 5-point capacitive touch supports operation with fingers or gloves (thickness ≤2mm), solving the pain point that operators in industrial sites cannot use touch functions while wearing protective gloves. The touch response time is ≤10ms, ensuring smooth and delay-free operations such as clicking, sliding, and zooming. It supports custom shortcut buttons—operators can set frequently used functions (e.g., "emergency shutdown," "process parameter switching") as desktop shortcut icons, which can be triggered with one click, reducing the operation time from the traditional 3 steps to 1 step.
• Multi-Page and Animation Display: It supports unlimited hierarchical page switching, and different pages (e.g., "Reactor Area," "Distillation Tower Area," "Utility Area") can be created according to process divisions, with quick navigation via the top navigation bar. It supports dynamic animation effects—for example, valve opening/closing status is displayed through rotation animation, and pump operation status is presented through speed simulation animation. This makes equipment status more intuitive, allowing operators to quickly determine whether the equipment is operating normally.

2. Multi-System Compatibility and Data Interaction

• Full-Protocol Coverage Communication: It natively supports mainstream industrial protocols such as Profinet, EtherNet/IP, and Modbus, and can connect to ABB 800xA DCS, Siemens S7-1500 PLC, and Rockwell frequency converters simultaneously to achieve centralized data acquisition. In intelligent manufacturing factories, the terminal can collect equipment operation parameters from PLCs and obtain production plans from MES systems, displaying "equipment status - production progress - quality data" on the same page to realize integrated display of multi-source data.
• OPC UA Standardized Data Interaction: It supports the OPC UA protocol, which serves as a "bridge" for standardized transmission of industrial data. It can convert private data from equipment of different manufacturers into a standardized format, enabling data interaction with cloud platforms (e.g., ABB Ability™ Cloud). In wind farms, the terminal can upload wind turbine operation data to the cloud via OPC UA, realizing remote monitoring and fault diagnosis.
• High-Speed Data Processing and Storage: The industrial-grade Core processor, paired with 4GB memory, can process over 1,000 real-time data points simultaneously, with a page refresh cycle of ≤500ms to ensure data real-time performance. The 64GB SSD can store 3 months of historical data (sampling period: 1s) and supports querying historical trends by time and parameter type. For example, in the query of historical curves of drum water level in the power industry, water level fluctuations over the past month can be traced, providing data support for process optimization.
