Product Description:
WIFI remote control can support the synchronous transmission operation of one computer connected to multiple machines, and can be connected to up to 100 machines at the same time. One machine can use multiple computers to send remotely. Each computer can send and operate the machine separately without the need for a special computer to operate. For graphic advertising stores, the machine location can be placed at will, and remotely sent by WIFI, and the machine does not need to be connected to the machine with traditional USB data cable, making it more convenient to use. You can also use a USB drive to operate offline without using a network or USB cable. Through the printer, marking points and patterns are printed out, and the machine automatically feeds paper, automatically positions, automatically cuts, and automatically outputs paper, realizing automatic operation.
The paper feed size 320X700mm is suitable for a wide range of paper, high-pressure cutting and high-definition camera scanning, which is suitable for a wider range of materials and has better paper jam cutting effect. The three modes of transmission meet the use of different environments. The machine supports six languages and has a wider range of operational applicability.
The operation software adopts the CDR+ plug-in mode, and generates corner marking points with one click. The plug-in automatically generates marking points according to the size and content of the paper. It can automatically generate a QR code. The machine automatically recognizes the file cutting according to the QR code. It can cut files of different contents at the same time, without cutting incorrectly and breaking, and scanning and cutting is more accurate. Reasonably design marking points, with a minimum margin of 5mm, saving maximum cutting material, and automatically adjust the position of marking points according to the typesetting and printing needs. The scanning method adopts camera positioning, with a wider scanning range and a higher success rate. It can identify more than ten different materials, such as: coated paper self-adhesive, kraft paper self-adhesive, PVC self-adhesive, fragile self-adhesive, etc., which greatly increases the recognition rate and cutting accuracy, making scanning faster.
The two sides of the platform use double-linked centered paper feeding, and the thickened baffle is positioned simultaneously. The baffle on both sides of the paper feeding for a long time will not loosen, and the paper blocking is more stable, ensuring that the paper feeding will not tilt, and cutting is more accurate. The centered paper feeding ensures the consistency of pressure on both sides.
Adopt a dual paper feed system, centered and double-wheeled paper feed, and two-wheeled auxiliary paper feed. The paper feed pressure can be adjusted freely to meet the smooth paper removal of paper with different thicknesses. The machine adopts anti-double-shot programming to effectively reduce the phenomenon of double-shots. Increase the large cowhide feeding wheel to increase friction, avoid double sheets, and ensure smooth paper feeding. Heavy Dual Dual Row Paper Pressing Roller, 20 springs have a pressure, a greater pressure, a more stable paper pressing, and paper removal is not easy to tilt. It realizes continuous cutting of single sheets and stable paper feeding. There is no need to manually operate the paper loading sheets and can work without being on duty. The paper feeding has been upgraded to an enlarged paper tray to ensure smoother paper loading and smoother paper handling. It can place about 150 sheets of paper at a time. Reduce the number of paper loading and save labor. Increase and widen the drawer-type paper connection box, design a humanized paper pickup method, and save space.
For materials of different materials, the brightness of the LED light can be adjusted at will, improving the success rate of scanning. Effectively protect the eyes when watching the cut effect. High-performance precision structure, built-in automatic air suction device, the paper is smoother, ensuring more uniform paper pressure and more accurate cutting.
Technical parameters:
Model Shanghai Xiangbao intelligent die-cutting machine
Display mode Color touch screen
Cutting width 320mm
Feed length 700mm
Cutting accuracy 0.01mm
Speed 800mm/s
Pressure 160 (about 2000g)
Voltage: Support 110V/220V
Paper capacity 150 sheets
Transmission method WIFI, U disk, USB data cable
Operating software Ai (CS6 2018/2019) corelDRAW (x4-x8, 2017-2019)
Computer system Windows7-10, plug-in does not support Apple system
Net weight: 61KG
Gross weight: 64 kg
Expanded size (approximately) Length 1040mm * Width 710mm * Height 530mm
Unexpanded size (approximately) Length 520mm * Width 710mm * Height 390mm
Packing box size (approximately): 840*630*620mm
