14Kw Commercial Swimming Pool Heat Pump Water Heater

14Kw Commercial Swimming Pool Heat Pump Water Heater thumbnail-1
14Kw Commercial Swimming Pool Heat Pump Water Heater thumbnail-2
14Kw Commercial Swimming Pool Heat Pump Water Heater thumbnail-3
14Kw Commercial Swimming Pool Heat Pump Water Heater thumbnail-4
14Kw Commercial Swimming Pool Heat Pump Water Heater thumbnail-5
14Kw Commercial Swimming Pool Heat Pump Water Heater photo-1
14Kw Commercial Swimming Pool Heat Pump Water Heater photo-2
14Kw Commercial Swimming Pool Heat Pump Water Heater photo-3
14Kw Commercial Swimming Pool Heat Pump Water Heater photo-4
14Kw Commercial Swimming Pool Heat Pump Water Heater photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Certification:
CE, ISO9001, CCC, ROHS, Other, TUV
Application:
Villa Family, Sauna and Swimming Pool, Beauty Salons, Other
Heat Source:
Air-source
Contact Supplier Request Quote Chat Now
Guangzhou Canova Heating & Refrigeration Equipment Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Certification CE, ISO9001, CCC, ROHS, Other, TUV
Application Villa Family, Sauna and Swimming Pool, Beauty Salons, Other
Heat Source Air-source
Heat Temperature 50-70°C
Work Environment Common Heat Pump
Compressor Copeland Scroll
Refrigerant R407C / R410A
Heat exchanger Titanium tube in PVC shell
Transport Package Plywood case
Specification 14kw
Trademark Canova
Origin Guangzhou, China
Model
HLRD9-YC HLRD15-YC HLRD18-YC HLRD30-YC HLRD36-YC
Heating capacity Kw 14.0 23.5 28.0 50 58
Btu/h 47768 80182 95536 170600 197896
COP
5.56 5.58 5.53 5.65 5.62
Cooling capacity Kw 8.8 14.8 16.8 30.5 35.8
Btu/h 30026 50498 57322 104066 122150
EER
3.32 3.34 3.29 3.41 3.38
Max water oulet temp ℃ 45
Power supply V/Hz 220V~240V/50Hz 380V~415V/50Hz
Rated input power(heating) Kw 2.52 4.21 5.06 8.85 10.32
Rated input current(heating) A 12.1 7.5 9.1 15.8 18.4
Max input Power Kw 3.5 6 7.2 12 14
Max input current A 16.7 10.7 12.9 21.5 25.0
Ambient temp ℃ (-10℃~43℃）
Heat exchanger
Titanium tube in PVC shell
Refrigerant
R407C/R410A
Compressor type
Scroll
Number of compressor
1 1 1 2 2
Number of fan
1 1 1 2 2
Fan air flow volume m³/h 3900 6500 6500 13000 13000
Fan direction
Vertical
Fan input power W 80 250 250 250*2 250*2
Fan rotation speed RPM 840 850 850 850 850
Noise dB(A) ≤54 ≤56 ≤58 ≤61 ≤62
Pipe diameter mm Rc1-1/2" Rc1-1/2" Rc1-1/2" Rc2" Rc2"
Water flow volume m³/h 6 10 12 21 25
Net weight kg 90 114 214 244 276
Product Dimension mm 710/710/855 750/750/1100 750/750/1100 1450/705/1375 1450/705/1375

Features:

· Titanium tube in PVC shell heat exchanger

· Compact structure

· Intelligent defrosting

· Stable running,economic&durable

· Easy installation&operation

· Cooling in summer&heating in winter


Product Tags: Commercial pool heat pump , Swimming Pool Heat Pumps , Water Chillerer heat pumps
