5X00226G01 EMERSON Relay Output Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.
1Yr
5X00226G01 EMERSON Relay Output Module thumbnail-1
5X00226G01 EMERSON Relay Output Module thumbnail-2
5X00226G01 EMERSON Relay Output Module thumbnail-3
5X00226G01 EMERSON Relay Output Module thumbnail-4
5X00226G01 EMERSON Relay Output Module thumbnail-5
5X00226G01 EMERSON Relay Output Module photo-1
5X00226G01 EMERSON Relay Output Module photo-2
5X00226G01 EMERSON Relay Output Module photo-3
5X00226G01 EMERSON Relay Output Module photo-4
5X00226G01 EMERSON Relay Output Module photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





5X00226G01
 5X00226G01 is a relay output module in Emerson's Ovation distributed control system (DCS), designed to convert digital control signals into physical relay actions for driving external devices. The following is a detailed overview:
Technical Specifications

  • Output Type: Relay output (Form C, SPDT - Single Pole Double Throw)

  • Channel Quantity: 8 independent channels

  • Contact Rating:

    • 250V AC / 30V DC (maximum voltage)

    • 5A per channel (resistive load), 2A per channel (inductive load)

  • Contact Resistance: ≤50 mΩ (initial value)

  • Insulation Resistance: ≥100 MΩ (500V DC)

  • Mechanical Life: ≥10 million operations (no load)

  • Electrical Life: ≥500,000 operations (full load)

  • Power Supply: 24V DC (for module operation, separate from relay power)

  • Power Consumption: ~8W (module) + relay load power

  • Operating Temperature: -40°C to +70°C

  • Storage Temperature: -40°C to +85°C

  • Humidity Environment: 5%–95% (non-condensing)

  • Protection Level: IP20 (front panel)

  • Physical Dimensions: 133mm (W) × 127mm (H) × 76mm (D)

  • Weight: Approximately 0.8kg


5X00226G01 (1)


Product Features

  1. Industrial-Grade Relay Design

    • High-reliability relays with arc suppression technology extend contact life, suitable for frequent switching in harsh industrial environments.

  2. Independent Channel Control

    • 8 channels support individual on/off control, each with an LED indicator for real-time status monitoring.

  3. Electrical Isolation

    • Channel-to-channel and channel-to-chassis isolation (500Vrms) prevents cross-interference and ground loops.

  4. Hot-Swap Capability

    • Modules can be replaced without powering off the system, minimizing maintenance downtime and production interruptions.

  5. Comprehensive Diagnostic Functions

    • Built-in self-test for relay contact status, open/short circuit detection, and fault alarm output via front-panel indicators and system logs.

  6. Flexible Wiring Options

    • Terminal blocks support both screw-down and quick-connect wiring for field devices, adapting to different installation requirements.



5X00226G01 (3)






Related products:


EMERSONKJ2003X1-BA2
EMERSON1C31224G01
EMERSON1C31227G01
EMERSON1X00416H01
EMERSON1C31129G03
EMERSONSE3008
EMERSON5X00605G01


Product Tags: 5X00226G01 , EMERSON , relay output module
