5X00226G03 EMERSON High-power Relay Output Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.
1Yr
5X00226G03 EMERSON High-power Relay Output Module thumbnail-1
5X00226G03 EMERSON High-power Relay Output Module thumbnail-2
5X00226G03 EMERSON High-power Relay Output Module thumbnail-3
5X00226G03 EMERSON High-power Relay Output Module thumbnail-4
5X00226G03 EMERSON High-power Relay Output Module photo-1
5X00226G03 EMERSON High-power Relay Output Module photo-2
5X00226G03 EMERSON High-power Relay Output Module photo-3
5X00226G03 EMERSON High-power Relay Output Module photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





5X00226G03

 5X00226G03 is a high-power relay output module in Emerson's Ovation distributed control system (DCS), designed for driving heavy-duty industrial loads with enhanced reliability and safety features. The following is a detailed overview:
Technical Specifications

  • Output Type: Electromechanical relay (Form C, SPDT) with enhanced load capacity

  • Channel Quantity: 8 independent channels

  • Contact Rating:

    • 250V AC / 30V DC (max voltage)

    • 10A per channel (resistive load), 5A per channel (inductive load)

  • Contact Resistance: ≤30 mΩ (initial)

  • Insulation Resistance: ≥100 MΩ (500V DC)

  • Mechanical Life: ≥10 million operations

  • Electrical Life: ≥1 million operations (full load)

  • Power Supply: 24V DC (module) + separate load power

  • Power Consumption: ~12W (module) + load power

  • Operating Temperature: -40°C to +70°C

  • Dimensions: 177mm (W) × 127mm (H) × 76mm (D)

  • Weight: ~1.1kg



5X00226G03 (2)


Functional Applications

  • Heavy Machinery Control:

    • Large motor starters, industrial furnace switches, and compressor relays.

  • Power Distribution:

    • Circuit breaker control, transformer tap changers, and backup power switches.

  • Process Safety:

    • Emergency shutdown (ESD) systems, fire suppression relays, and safety interlocks.



5X00226G03 (4)






Related products:


EMERSONKJ2003X1-BA2
EMERSON1C31224G01
EMERSON1C31227G01
EMERSON1X00416H01
EMERSON1C31129G03
EMERSONSE3008
EMERSON5X00605G01


Product Tags: 5X00226G03 , EMERSON , high-power relay output module
