5X00481G04 EMERSON Multi-protocol Communication Interface Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.
1Yr
5X00481G04 EMERSON Multi-protocol Communication Interface Module thumbnail-1
5X00481G04 EMERSON Multi-protocol Communication Interface Module thumbnail-2
5X00481G04 EMERSON Multi-protocol Communication Interface Module thumbnail-3
5X00481G04 EMERSON Multi-protocol Communication Interface Module thumbnail-4
5X00481G04 EMERSON Multi-protocol Communication Interface Module thumbnail-5
5X00481G04 EMERSON Multi-protocol Communication Interface Module photo-1
5X00481G04 EMERSON Multi-protocol Communication Interface Module photo-2
5X00481G04 EMERSON Multi-protocol Communication Interface Module photo-3
5X00481G04 EMERSON Multi-protocol Communication Interface Module photo-4
5X00481G04 EMERSON Multi-protocol Communication Interface Module photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





5X00481G04

 5X00481G04 is an upgraded multi-protocol communication interface module for Emerson's Ovation distributed control system (DCS), designed to enhance data exchange capabilities between the DCS and intelligent field devices, legacy systems, or third-party equipment. Below is a detailed overview compiled from available information:
Technical Specifications

  • Supported Protocols: HART 7, Modbus RTU/TCP, Foundation Fieldbus H1, and Profibus DP

  • Interface Configuration: 12 isolated ports (configurable per protocol, 4 ports dedicated to high-speed protocols)

  • Data Transfer Rates:

    • HART 7: 1200 bps (backward compatible with HART 5/6)

    • Modbus RTU: 9600–115200 bps; Modbus TCP: 10/100 Mbps

    • Foundation Fieldbus H1: 31.25 kbps

    • Profibus DP: 9.6 kbps–12 Mbps (auto-negotiation)

  • Isolation: Channel-to-channel (2500Vrms) and channel-to-chassis (1500Vrms)

  • Power Supply: 24V DC (redundant inputs, 10–30V tolerance)

  • Power Consumption: ≤15W (including fieldbus power)

  • Operating Temperature: -40°C to +70°C

  • Storage Temperature: -40°C to +85°C

  • Humidity: 5%–95% non-condensing

  • Protection Class: IP20 (front panel); optional IP65 enclosure for harsh environments

  • Physical Dimensions: 150mm (W) × 120mm (H) × 80mm (D)

  • Weight: ~0.5kg



5X00481G04 (1)


Configuration & Programming

  • Software Tool: Emerson Ovation Configuration Tool (OCT) v5.0+ with Profibus/FF configuration plugins.

  • Key Settings:

    • Assign protocols to ports (e.g., Ports 1–4 for Profibus DP, 5–8 for HART).

    • Configure baud rates, parity, and timeout values per protocol.

    • Set up data mapping between field device variables and DCS tags (e.g., linking a flow transmitter’s PV to an Ovation analog input tag).

    • Enable redundancy parameters (e.g., primary/secondary path priorities).


5X00481G04 (3)






Related products:


EMERSONKJ2003X1-BA2
EMERSON1C31224G01
EMERSON1C31227G01
EMERSON1X00416H01
EMERSON1C31129G03
EMERSONSE3008
EMERSON5X00605G01


Product Tags: 5X00481G04 , EMERSON , multi-protocol communication interface module
