Help CenterTPU Layflat Hose High Pressure Water and Oil Field Use Frac Hose
Related Products
-
Oil and Gas Develop Use Large Diameter High Pressure Polyurethanes TPU Layflat Hose Discharge Water HoseNegotiableMOQ: 1 Bag -
Large Diameter High-Pressure Polyurethanes TPU Layflat Frac HoseNegotiableMOQ: 1 Bag
-
Large Diameter TPU Layflat Flexible Water HoseNegotiableMOQ: 1 Bag
-
Flexible High Pressure Large Diameter TPU Layflat Water HoseNegotiableMOQ: 1 Bag
-
TPU Layflat Frac Hose for Oilfield Shale Gas & Oil DevelopNegotiableMOQ: 1 Bag
Cover and Lining: TPU (Extrusion through-the-weave)
Reinforcement Jacket: 100% high tenacity Polyester Filament.
Temperature range:-50ºC to 80ºC (-58ºF to +178ºF)
Available length: 100m (330ft), 200m (660ft), 300m (990ft), 400m (1320ft)
Nipple and Clamp:
Nipple--->316 Stainless Steel
Clamp---->Ductile Iron
Gasket--->Viton Rubber
Hose Technical Specification:
| I.D. | Wall Thickness | Service Pressure | Minimum Burst Pressure | Weight |
| inch | Approx. inch | psi | psi | Approx. Lbs/ft |
| 4" | 0.138 | ≥250 | ≥750 | 0.94 |
| 6" | 0.150 | ≥250 | ≥750 | 1.41 |
| 8" | 0.177 | ≥300 | ≥900 | 2.28 |
| 10" | 0.197 | ≥300 | ≥900 | 3.75 |
| 12" | 0.228 | ≥200 | ≥600 | 4.3 |
| 14" | 0.205 | ≥150 | ≥450 | 4.96 |
| 16" | 0.205 | ≥150 | ≥450 | 5.1 |
Hebei Biaohui Rubber and Plastic Products Co., Ltd. main products include TPU flat hose series, fire hose series, industrial hose series, material conveying hose series, silicone hose series, metal hose series, PTFE hose series and matching joints, various rubber and plastic products and hose products.
