12 inch Polyurethane Hose Suitable for Shale Gas and Oil Development in Oil Fieldsater Hose
- 500 Bag / Bags per Month
- Tianjin Shanghai
- T/T
- 5 days
You May Like
Product Details
| Brand Name | Biaohui | Place of Origin | China | |
| Model Number | Frac hose | Material | Other, TPU | |
| Length | 50/100/200m | Thickness | 6mm | |
| Specification | 1 1/2“ - 16“ | Standard | international standard | |
| Weaving Type | Twill & Plain Weave | Working Pressure | 8-28bar | |
| Hose Coupling Structure | Coupling | Service Pressure | 8-28 Bar | |
| Color | Customize | Burst Pressure | 20-126 Bar | |
| Origin | China |
Product Description
TPU Layflat Hose
Oil and Gas Fracking Water Transfer Hose Layflat Water Hose
Cover and Lining: TPU (Extrusion through-the-weave)
Reinforcement Jacket: 100% high tenacity Polyester Filament.
Temperature range:-50ºC to 80ºC (-58ºF to +178ºF)
Available length: 100m (330ft), 200m (660ft), 300m (990ft), 400m (1320ft)
Nipple and Clamp:
Nipple--->316 Stainless Steel
Clamp---->Ductile Iron
Gasket--->Viton Rubber
Hose Technical Specification:
| I.D. | Wall Thickness | Service Pressure | Minimum Burst Pressure | Weight |
| inch | Approx. inch | psi | psi | Approx. Lbs/ft |
| 4" | 0.138 | ≥250 | ≥750 | 0.94 |
| 6" | 0.150 | ≥250 | ≥750 | 1.41 |
| 8" | 0.177 | ≥300 | ≥900 | 2.28 |
| 10" | 0.197 | ≥300 | ≥900 | 3.75 |
| 12" | 0.228 | ≥200 | ≥600 | 4.3 |
| 14" | 0.205 | ≥150 | ≥450 | 4.96 |
| 16" | 0.205 | ≥150 | ≥450 | 5.1 |
Hebei Biaohui Rubber and Plastic Products Co., Ltd. main products include TPU flat hose series, fire hose series, industrial hose series, material conveying hose series, silicone hose series, metal hose series, PTFE hose series and matching joints, various rubber and plastic products and hose products.
contact information:
Company Name: Hebei Biaohui Rubber Products Co., Ltd
Address: Zhanggehou Rubber and Plastic Base, Jing County, Hebei Province
Telehone: +86 15075803959
E-mail: info@biaohuihose.com
WhatsApp：+86 15075803959
WeChat ： +8615075803959
