MKBR Series Planetary Reducer Gearbox

MKBR Series Planetary Reducer Gearbox thumbnail-1
MKBR Series Planetary Reducer Gearbox thumbnail-2
MKBR Series Planetary Reducer Gearbox photo-1
MKBR Series Planetary Reducer Gearbox photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Planetary Gear Reducer
Application:
Motor, Electric Cars, Machinery, Marine, Agricultural Machinery, Car, Other
Installation:
Vertical Type
Contact Supplier Request Quote Chat Now
Su Zhou Hbn Group Co.,ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Planetary Gear Reducer
Application Motor, Electric Cars, Machinery, Marine, Agricultural Machinery, Car, Other
Installation Vertical Type
Layout Coaxial
Step Single-Step
Gear Shape Other, Straight teeth,Helical teeth
Hardness Hardened Tooth Surface
Origin China

Technical Specifications & Features:

Torque Performance:

  • Maximum Torque Range: 28-40Nm (T₁)

  • Rated Output Torque: 14-20Nm (T₂n)

  • Emergency Braking Capacity: 65Nm

Operational Parameters:

  • High-Speed Capability:

    • Maximum Input Speed: 8000 rpm

    • Rated Input Speed: 4000 rpm

  • Load Capacity:

    • Axial Force: 610N

    • Radial Force: 700N

Efficiency & Dynamics:

  • 90% Energy Efficiency (η)

  • Ultra-Low Inertia: 0.03 kg·cm³

  • Lightweight Design: 2.2 kg

Durability & Protection:

  • IP65 Rated Enclosure (Dustproof/Water Resistant)

  • Lifetime Lubrication System

  • Wide Temperature Range: -15°C to +45°C

Environmental Specifications:

  • Low Noise Operation: ≤63 dB(A)

  • Standard Industrial Gray Finish

Engineering Advantages:
✓ Exceptional speed capability for precision applications
✓ Optimized power-to-weight ratio
✓ Maintenance-free operation
✓ Reliable performance in demanding conditions

Typical Applications:

  • High-speed automation systems

  • Precision robotics

  • CNC machinery

  • Medical equipment drives

  • Packaging systems


Product Tags: precision gear reducer , reducer gearbox , planetary gear reducer
