MKDR Series Planetary Reducer Gearbox

Performance Highlights:

• Torque Range: 60-90Nm (Max) / 30-45Nm (Rated)

• High-Speed Operation: 6000 rpm (Max) / 3000 rpm (Rated)

• Exceptional Load Capacity: 2700N Axial / 3000N Radial Force

• Premium Efficiency: 90% Energy Conversion

Detailed Specifications:

1. Torque Performance

• Maximum Torque: 60-90Nm

• Rated Output Torque: 30-45Nm

• Emergency Braking Torque: 110Nm

2. Operational Parameters

• Speed Range: 3000-6000 rpm

• Moment of Inertia: 0.13 kg·cm²

• System Weight: 5.2 kg

3. Durability Features

• IP65 Protection Rating (Dustproof/Water Resistant)

• Lifetime Lubrication System

• Operating Temperature: -15°C to +45°C

4. Environmental Specifications

• Noise Level: ≤60 dB(A)

• Standard Color: Industrial Gray

Engineering Advantages:
✓ Optimized for high-torque applications
✓ Maintenance-free lifetime lubrication
✓ Robust construction for heavy-duty use
✓ Compact design with high power density
