Help CenterWet Pan Mill
Related Products
QS-110
Runner wheel thicknes≥ 16.5cms, one wheel weight ≥1030 KGS around, the machine total weight 4150KGS around,the power 5.5KW, handing capacity 5 T/D.
The grind bottom external diameter 202cms, inside diameter 145cms, the grind bottom width 27cms,inside groove width 21cms,total weight 760KGS.
Grinding basin diameter 255cms, lower edge diameter 215cms.
QS-120
Runner wheel thickness 18 cms, one wheel weight 1200 kgs around, the machine total weight 4900KG around,the power7.5KW, handing capacity 8 T/D.
The grind bottom external diameter 205cms, inside diameter 144cms,the grind bottom width 30cms,inside groove width 23 cms,total weight 860KGS.
Grinding basin diameter 255cms, lower edge diameter 215cms.
QS-130
Runner wheel thickness 24cms, one wheel weight 1990 KGS around, the machine total weight 7600KGS around,the power 11KW, handing capacity 10-12 T/D.
The grind bottom external diameter 210cms, inside diameter 140cms, the grind bottom width 34cms,inside groove width 26cms,total weight 1160KGS.
Grinding basin diameter 276cms, lower edge diameter 214cms.
Send Inquiry to This Supplier
