UKCA Split Core Current Transformer 150A/5A Meter Matching Transformer Clamp
US$ 5 - 8
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
Jiangyin spark
Place of Origin:
China
Model Number:
XH-SCT-T24
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UKCA Split Core Current Transformer 0.33V Output 24mm DiameterUS$ 5 - 8MOQ: 5 Pieces -
KCT-816 2500:5A Busbar Type Split Core Current TransformersUS$ 12.9 - 58MOQ: 1 Piece
-
5A Output Busbar Split Core Current Transformer for Monitoring DevicesUS$ 12.9 - 58MOQ: 1 Piece
-
KCT-816 Split Core Busbar Current Transformer Window Type 160*80mmUS$ 12.9 - 58MOQ: 1 Piece
-
Split Core Current Transducer DCT24-300AAC/4-20mA DC OutputUS$ 8 - 10MOQ: 1 Piece
Brand Name
Jiangyin spark
Place of Origin
China
Model Number
XH-SCT-T24
Usage
Electronic
Phase
Single
Coil Number
Other
Coil Structure
Other
Specifications Of SCT-T24 Split Core Current Transformer
Maximum continuous primary current 5A to 300Aac
Output: 5A
Accuracy: ± 1% from 5% to 120% of rated current
Insulation Voltage: 600VAC
Maximum Primary Voltage: 3kV(Insulated Conductor)
Phase angle: Less than 2 degrees at 50% of rated current
Frequency Range: 50 Hz to 400 Hz
Operating Temperature: -15C to 60C.
CE recognized, and RoHS compliant
Output and leads can be customized
| Model | Input(A) | Output(A) | Overload current(A) | Accuracy(5%-120%)F(I)% | Accuracy(5%-120%)δ(I)° |
| XH-SCT-T24B-100A/5A | 100 | 5 | 160 | ≤1.5% | ≤1.5° |
| XH-SCT-T24B-150A/5A | 150 | 5 | 240 | ≤1% | ≤1° |
| XH-SCT-T24B-200A/5A | 200 | 5 | 320 | ≤1% | ≤0.5° |
| XH-SCT-T24B-250A/5A | 250 | 5 | 420 | ≤1% | ≤0.5° |
| XH-SCT-T24B-300A/5A | 300 | 5 | 420 | ≤1% | ≤0.5° |
Drawing Size Of SCT-T24 Split Core Current Transformer
