ISO Aluminum Core EV High-Voltage Cable

Name: ISO Aluminum Core EV High-Voltage Cable
Brand: OMG'
SKU: 172638005
Availability: InStock

Negotiable MOQ: 50 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

OMG'

Place of Origin:

China

Model Number:

ISO 19642

Guangdong OMG Transmitting Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name OMG'

Place of Origin China

Model Number ISO 19642

Type High Voltage

Application Other, Electric Vehicles

Insulation Material XLPE

Jacket Other, XLPE

Conductor Material Aluminum

Reference standard: ISO 19642-2019-6、IS0 19642-2019-10

Features
1.Conductor	1.Rated temperature ：-40℃～+(125℃, 150℃)
Material: AAL	2.Rated Voltage：AC 600V/DC 900V;AC 1000V/DC 1500V
2.Insulation	3.Short-term Aging：240h,Comply with ISO 19642-2019
Material：XLPE	4.Long-term Aging： 3000h,Comply with ISO 19642-2019
Color：Orange	5.Flame Test：Comply With ISO 19642-2019
3.Shielded	6.Min：Bending Radius: 6OD@OD﹤15mm ; 8OD@OD≧15mm
Material：Tinned Copper	7.Dielectric Voltage：5kVac/5min. No Breakdown
4.Sheath	8.Oil Resistance：Comply With ISO 19642-2019
Material: XLPE	9.Anti-tear Performance ：>15N/mm
Color：Orange	10.Environmental Requirements ：Compliant with RoHS 2.0 and REACH

Aluminum conductor specifific structure size according to the standard

Nominal conductor cross-section		Strand		Conductor
		Quantity	Diameter	Diameter	Twistength	Cross-section		Resistance at +20°C
Al	Cu	Al	Al	Al	Al	Al		Bare Al & Cu
mm²	mm²	PCS	mm	mm		mm²		mΩ/m
nom	nom	nom	max	max	max	max	min	max
10	6	49	0.51	4.30	not specified	9.81	9.09	3.100	2.870
17	10	84	0.51	5.50		16.70	15.50	1.820	1.690
27	16	133	0.51	7.00		26.20	24.30	1.160	1.070
42	25	210	0.51	9.00		40.90	37.90	0.743	0.688
59	35	294	0.51	10.60		57.70	53.50	0.527	0.488
85	50	420	0.51	12.90		82.70	76.50	0.386	0.341
120	70	608	0.51	15.10		117.00	109.00	0.259	0.240
160	95	798	0.51	17.90		155.00	144.00	0.196	0.181
