Mobile Phone Double Sided Adhesive Tape With 0.075 PET Foil Thickness
- 10000000 Piece / Pieces per Month
- Dongguan
- T/T
- 3 days
- High Conductivity Thermal Epoxy Glue For Bonding Electronics Solvent Resistance
- Laptop Cooling Pads TIG780-18 Liquid Metal Thermal Conductive Paste Grease For CPU GPU Ultra
- CPU Heatsink Cooling 3.8W Thermal Conductive Grease thermal conductive gap filler
- China Silicone Thermal Pad Distributor for LED Lamp CPU GPU Cooling
- Wholesale Customized thermal conductive gap filler for GPU CPU Cooling
- Hot selling 7W thermal silicone Insulation Pad for gpu cpu cooling pad 0.5mmT Low thermal resistance
Product Details
Brand Name: | ZIITEK | Place of Origin: | China | Model Number: | Z-paster2130-PE series |
Material: | Other, N/A | Feature: | Heat-Resistant | Design Printing: | No Printing |
Adhesive Type: | Pressure Sensitive | Adhesive Side: | Double Sided |
Product Description
Z-paster2000-PE series is a insulators grade PET foil double coated with a special aggressive acrylic adhesive system with high quick stick, excellent acrylic cohesive strength, good low temperature performance and excellent high temperature resistance.
Z-paster2000-PE series | ||||
Property | 2080-PE | 2130-PE | 2250-PE | 2380-PE |
PET Foil Thickness (mm) | 0.025± 0.005 | 0.075± 0.005 | 0.188± 0.01 | 0.32± 0.01 |
Total Thickness (mm) | 0.08± 0.015 | 0.13± 0.015 | 0.25± 0.02 | 0.38± 0.025 |
Tensile (N / 25mm width) | 135 | 160 | 260 | 350 |
Elongation (%) | 1.5 | 0.9 | 0.6 | 0.4 |
Adhesion: Peel (PSTC #1) N / 25mm width | 32.8 | 32.8 | 32.8 | 32.8 |
Adhesion: Shear (PSTC #7) 24+ hrs @ Kpa | 0.6 | 0.6 | 0.6 | 0.6 |
Low Temperature Application (oC) | 17.9 | 17.9 | 17.9 | 17.9 |
High Temperature Resistance (oC) | 120 | 120 | 120 | 120 |
Low environmental Resistance (oC) | -30 | -30 | -30 | -30 |
Release Liner | 83 lb.polycoated densified paper |
Factory file
Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.
