SH/T0361 Yuexiu Type Guide Oil Stick-Slip Property Tester

Product model: JF0361

Instrument introduction

This instrument conforms to the SH/T0361 Yuexiu type stick-slip property test method, applicable in Yuexiu sex stick-slip test machine, evaluation of guide rail lubricant anti-stick-slip performance, the specific index for the static and dynamic friction coefficient of the difference △ μ. Stick-slip image, is the friction coefficient of the two friction surfaces between the changes caused by the △ μ value is smaller, the lubricant's anti-stick-slip better.

Technical Parameter

1. Applicable standards: SH/T0361

2. Load range: 200kgf, hydraulic pressure loading;

3. Loading mode: weight lever loading or force application device automatic loading

4. Test force control error: ≤±1%.

5. Horizontal speed of friction block: ㎜/min, infinitely adjustable speed.

6. Horizontal displacement control range: 0.05-10mm/min

7. Time record: 0-9999min, switchable in minutes and seconds.

8. Displacement measurement range: 0-20mm

9. Displacement measurement control accuracy: 0.01mm

10. Measuring range of friction sensor: 0-1000N

11. Host power supply: 380V 50Hz three-phase four-wire system

Main Feature

1. Adopt windows system control, Chinese operation interface;

2. Addition lever weights loaded with the traditional clutch loading mode, system stability, loading accuracy

3. Addition software configuration automatic diagnostic system, convenient to judge the instrument failure and daily maintenance

4. One-key operating system, automatic pressurisation, automatic acceleration, automatic oscillation, real-time recording of test parameters.

Adopt computer to collect and process the data, display speed, temperature, time, torque, motor power and other parameters, and process the data, can curve, table and other ways to store, print, convenient and intuitive, more accurate analysis of the test research.
