SH/T0701 Total Sediment of Fuel Oil Tester

Product model: JF0701

Instrument introduction

The instrument is suitable for total deposits in residual fuel oils and distillate fuel oils containing residual components.

Technical Parameter

1. Applicable standards: SH/T0701, SH/T0702

2. Test samples: 25g

3. Waste flask capacity: 500ml

4. Measuring range: 0.5%(m/m)

5. Test Unit: 2 Units

6. Filter paper: Aperture: 0.0016mm; diameter: 47mm

7. Vacuum pressure: 40 kpa

8. Working power supply: AC220V, 50Hz

9. Engine power: 1000W

10. Instrument dimensions: Aging bath: 570*600*480mm

Filtration: 600*600*550mm

11. Net weight: Aging bath: 36KG;

Filtration: 23KG

Main Feature

1. Equipped with a special aging bath.

2. Standard filter element with heating and cooling coils.

3. Glass fiber filter paper,with the aperture of 0.0016mm and the diameter of 47mm.

4. Stainless steel ball valve switch heat source and cold source.

5. Digital display time relay controls working time.

6. Microcomputer PID temperature controller, PT100 temperature sensor, high temperature control accuracy.
