Manifold ignition Test of Flame Retardant Hydraulic Fluid Tester
Product model: JF0567
Instrument introduction
This instrument is designed and manufactured in accordance with SH/T 0567 standard; it is used for the determination of flame retardant hydraulic fluid manifold fire test.
Technical Parameter
1. Applicable standards: SH/T0567
2. Temperature control method: Electric rod heating
3. Temperature control range: Rt ~ 800 ℃ and it can be set
4. Temperature control precision: ±4℃
5. Heating power: 6000W
6. Power supply: AC220V±10％, 50Hz
Main Feature
1. The instrument adopts foreign advanced PID fuzzy logic temperature control system, and the temperature control is accurate;
2. The heating system adopts silicon carbide rod heating with fast speed;
3. The instrument adopts a new type of refractory insulation material outside the furnace chamber, which is lightweight, heat-resistant and heat-insulating;
4. The temperature control / temperature measuring device and high temperature furnace body are split type;
The upper part of the instrument is equipped with quartz glass window which is convenient to observe the fire situation.
