CNOMO D65 5212 ADDITION Metalworking Fluid Anti-Foaming Tester

Metalworking Fluid Anti-Foaming Tester

Product model: JF1015

Instrument introduction

This instrument is designed and manufactured in accordance with CNOMO D65 5212/ NF T60-185 and is suitable for the determination of anti-foaming property of metal working fluids.

Technical Parameter

1. Applicable standards: NF T60-185, CNOMO D65 5212

2. Temperature control range: 10 ~ 80 ± 0.1℃

3. Refrigeration method: Compressor cycle refrigeration

4. Temperature control mode: Digital PID digital display

5. Timing mode: The digital display timing is set according to the experimental time. When the set time is reached, the water pump motor will stop automatically and give an alarm.

6. Centrifugal pump: DC anti-corrosive speed regulating pump 10 L / min

7. Flow meter: Liquid flow meter, 0 ~ 6 L / min can be adjusted arbitrarily

8. Glass measuring cylinder: 2000ml laminated glass measuring cylinder

9. Working power supply: AC220V±10%, 50HZ

10. Power of the whole machine: 1200W

11. Instrument size: 700*640*1000mm

12. Net weight: 41KG

13. HS Code: 9027899090

Main Feature

1. Compressor cycle refrigeration

2. DC anti-corrosion speed regulating pump 10 L / min

3. Liquid flow meter, 0 ~ 6 L / min can be adjusted arbitrarily

4. 2000ml laminated glass measuring cylinder

5. The digital display timing is set according to the experimental time. When the set time is reached, the water pump motor will stop automatically and give an alarm
