LB170E01-SL01 LG 17.0 Inches Panel Type A-Si TFT-LCD

Panel brand LG Display (LG Display)

Panel model LB170E01-SL01

Panel size 17.0 inches Panel type a-Si TFT-LCD, LCD module

Resolution 1280(RGB)×1024, SXGA, 96PPI pixel layout RGB vertical stripes

The display area is 337.92 (w) × 270.336 (h) mm.

The external dimension is 368 (w) × 306 (h) × 14.8 (d) mm.

The visible size is 341.5 (w) × 274.6 (h) mm.

Surface treatment fog surface, Hard coating (3H)

Brightness (cdm²)400 (Typ.) contrast ratio 1000 1 (Typ.) [transmission]

Optical mode IPS, normally black display, transmissive

Viewing angle 89898989 (Typ.)(CR≥10)

Response speed 14 (Typ.)(G to G) ms

Color quantity 16.7M, 72% NTSC

Backlight type WLED, 50K hours, including LED driver.

Screen weight of 1.26Kgs (Typ.) is suitable for

Refresh frequency 60Hz Touch function no touch.

Signal system LVDS (2 ch, 8-bit), terminal, 30 pins

Supply voltage is 5.0V (Typ.).

Storage temperature-20 ~ 80 C and working temperature-10 ~ 70 C.
