Home > Consumer Electronics > Display & Accessories > LCD Module > G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD,

G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD,

G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, thumbnail-1
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, thumbnail-2
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, thumbnail-3
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, thumbnail-4
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, thumbnail-5
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, photo-1
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, photo-2
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, photo-3
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, photo-4
G190EG02 V1 AUO 19.0 Inches Panel Type A-Si TFT-LCD, photo-5
Negotiable MOQ: 1 Bag (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2013
Port of Shipment:
shanghai
Contact Supplier Request Quote Chat Now
FlinTeck
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us

Panel brand AUO (AUO)

Panel model G190EG02 V1

Panel size 19.0 inches

Panel type a-Si TFT-LCD, LCD module

The resolution is 1280 (RGB) × 1024, SXGA, and the pixel layout of 86ppi is RGB vertical stripes.

The display area is 376.32 (w) × 301.056 (h) mm.

The external dimension is 396 (w) × 324 (h) × 18.9 (d) mm.

Open area 380.32 (horizontal) ×305.06 (vertical) mm surface treatment fog surface.

Display brightness of 300 cd/m² (Typ.) and contrast ratio of 2000:1 (Typ.) (transmission).

The recommended viewing angle response time is 15/5 (typ.) (tr/TD) ms.

Viewing angle 89/89/89/89 (Typ.)(CR≥10)

Display mode MVA, normally black display, transmissive

Support color 16.7M, 70% NTSC.

Type of light source WLED, 50K hours, including LED driver.

Weight 1.75Kgs (Typ.) Application product frame frequency 60Hz touch technology no touch.

Interface type 30 pins LVDS (2 ch, 8-bit), terminal

The voltage supply is 5.0V (Typ.)

Working temperature of application environment: 0 ~ 60 °C; Storage temperature:-20 ~ 60 C.


Product Tags: AUO19.0 inches , G190EG02 V1
