Help CenterG070VW01 V0 AUO 7-inch LCD
Related Products
AUO (AUO)
Model G070VW01 V0
Diagonal dimension 7.0 inch
Type a-Si TFT-LCD, liquid crystal module
The resolution is 800(RGB)×480 WVGA 133PPI.
Pixel arrangement RGB vertical strip
The display area is 152.4 (horizontal) ×91.44 (vertical) mm.
The external dimension is 170 (horizontal) ×111 (vertical) ×8 (thickness) mm.
The opening area is 155.2 (horizontal) ×94.24 (vertical) mm.
Surface treatment fog surface, Hard coating (3H)
Display brightness is 400 cd/m² (Typ.)
Contrast ratio 750:1 (Typ.) (transmission)
Recommended perspective-
Response time 20/10 (Typ.)(Tr/Td) ms
Viewing angle 80/80/80/80 (Typ.)(CR≥10)
Display mode TN, normally white display, transmissive
Support color 262K/16.2M, 60% NTSC.
Type of light source WLED, 50K hours, including the application product with LED driver weighing 165/175g (Typ./Max.).
Frame frequency is 60Hz.
Touch technology touchless interface type 20 pins LVDS (1 ch, 6/8-bit), terminal
The voltage supply is 3.3V (Typ.)
Working temperature of application environment:-30 ~ 85 C; Storage temperature:-30 ~ 85 C.
Send Inquiry to This Supplier
