G121X1-L04 Innolux 12.1 Inch LCD Screen

Innolux 12.1 inch LCD screen

Model G121X1-L04

Diagonal dimension 12.1 inch

Type a-Si TFT-LCD, liquid crystal module

The resolution is 1024(RGB)×768 XGA 105PPI.

Pixel arrangement RGB vertical strip

The display area is 245.76 (horizontal) ×184.32 (vertical) mm.

Appearance dimension is 260.5 (horizontal) ×204 (vertical) ×7.7 (thickness) mm.

The opening area is 249.0 (horizontal) ×187.5 (vertical) mm.

Surface treatment fog surface, Hard coating (3H)

Display brightness 500 cd/m² (Typ.)

Contrast ratio 700:1 (Typ.) (transmission)

Recommended viewing angle-response time 5/11 (Typ.)(Tr/Td) ms

Viewing angle 80/80/70/70 (Typ.)(CR≥10)

Display mode TN, normally white display, transmissive

Support color 262K/16.2M, 63% NTSC.

Type of light source WLED, 30K, including LED driver.

Application product with weight of 435/465g (Typ./Max.)

The frame frequency is 60Hz. Touch technology is non-touch.

Interface type 20 pins LVDS (1 ch, 6/8-bit), terminal

Voltage supply is 3.3/5.0V (Typ.).

Working temperature of application environment:-30 ~ 70 C; Storage
