G215HVN01.3AUO 21.5 inch LCD screen

AUO (AUO)

Model G215HVN01.3

Diagonal dimension 21.5 inch

Type a-Si TFT-LCD, liquid crystal module

The resolution is 1920(RGB)×1080 FHD 102PPI.

Pixel arrangement RGB vertical strip

Display area is 476.64 (horizontal) ×268.11 (vertical) mm.

The external dimension is 495.6 (horizontal) ×292.2 (vertical) ×24.05 (thickness) mm.

The opening area is 479.84 (horizontal) ×271.31 (vertical) mm.

Surface treatment fog surface, Hard coating (3H)

Display brightness is 1000 cd/m² (Typ.)

Contrast ratio 5000:1 (Typ.) (transmission)

The response time of the recommended viewing angle is 20/5 (typ.) (tr/TD) ms.

Viewing angle 89/89/89/89 (Typ.)(CR≥10)

Display mode VA, normally black display, transmissive

Support color 16.7M, 73% NTSC.

Type of light source WLED [18S4P×2CN], 50K hours, including LED driver.

Weight 1.63±0.16Kgs Application product frame frequency 60Hz

Touch technology touchless interface type 30 pins LVDS (2 ch, 8-bit), terminal

The voltage supply is 5.0V (Typ.) and the working temperature of the application environment is-20 ~ 80 C; Storage temperature:-20 ~ 80 C.
