X6330 Vertical Turret Milling Machine With Taiwan Milling Turret Head
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
X6132 Factory Direct Sales Universal Knee-type Milling Machine PriceNegotiableMOQ: 1 -
X6228B China Universal Milling Machine With Swivel HeadNegotiableMOQ: 1
-
X6336 Chinese Vertical and Horizontal Dual-purpose Metal Milling MachineNegotiableMOQ: 1
-
Z3063X20/1 Metal Cutting Hydraulic Radial Drilling Machine With CENegotiableMOQ: 1
-
Z3063X20/1 China Hydraulic Radial Drilling Machine Metal DrillNegotiableMOQ: 1
Product Description
Features:
Rectangular guideway on Y and Z axis makes the machine stable and rigid.
The guideway on saddle is lined with TF wearable material.
Fixed structure is used to connect the mill head without addapter, which makes the cut intensity well.
Specificaiton |
X6323 |
X6325 |
X6330 |
||
Table size |
1067×230mm (Optional:1270×230mm) |
1270×254mm (Optional:1370×254mm) |
1370×305mm |
||
T-slotes (No./Width/Pitch) |
3/16/63mm |
3/16/65mm |
3/16/65mm |
||
Table travel (X/Y/Z) |
600×320×400mm |
800×400×400mm |
850×400×450mm |
||
Distance between spindle nose and table surface |
60-460mm |
0-460mm |
|||
Spindle speed |
66-4540rpm |
||||
Main motor power |
3HP |
5HP |
|||
Spindle taper |
R8 or NT30 |
NT40 |
|||
Travel of spindle sleeve |
127mm |
||||
Arm travel |
300mm |
400mm |
500mm |
||
Feed of spindle sleeve |
0.04/0.08/0.15mm/r |
||||
Milling head rotation |
swivel:45° tiltle:90° |
||||
Machine overall size (L*W*H) |
1500×1400×2150mm |
1700×1600×2150mm |
1750×1650×2150mm |
||
NW/GW |
950kgs |
1200kgs |
1350kgs |
||
You may find the accessories as you like:
Standard accessories:
1. Coolant system
2. Working lamp
3. Taiwan milling turret head
4. 58pcs clamping kit
5. Oil tray
6. 160mm vice
7. 11pcs spindle kit
8. tool box with tools
8. tool box with tools
Optional accessories:
1. Taiwan Variable speed head
2. X/Y/Z digital read out
3. X/Y power feed
4. Z axis lifting motor
Detailed machine photos:
