LM1450A China Cnc Universal Metal Milling Machine Price for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XL6436CL Multi-function Swivel Head Knee Milling Machine for Metal WorkNegotiableMOQ: 1 -
XL6436CL China Knee Type Manual Universal Milling Machine for Metal WorkNegotiableMOQ: 1
-
XL6436C Cheap Manual Milling Machinewith CE ProtectionNegotiableMOQ: 1
-
XL6436Cchina Universal Milling Machine With Horizontal and Vertical Milling for Metal WorksNegotiableMOQ: 1
-
XL6436C Vertical Universal Milling Machine With Table Long Travel and Automatic Power FeederNegotiableMOQ: 1
Product Description
Main Features:
LM1450A universal swivel head milling machine is based on theLM1450, installation of rotary table 45 degrees, processing of a wide range, three-axes automatic feeds, large torque and strong power, 1.5KW, fast-moving 2000mm/min. Spindle taper is ISO50.
LM1450A universal swivel head milling machine is based on theLM1450, installation of rotary table 45 degrees, processing of a wide range, three-axes automatic feeds, large torque and strong power, 1.5KW, fast-moving 2000mm/min. Spindle taper is ISO50.
Specification |
LM1450A |
Spindle taper |
ISO50(V) ISO50(H) |
Distance from vertical spindle to working table |
0-450mm |
Distance between spindle axis and ram surface |
100-500 mm |
Arm travel |
500mm |
Rabge of spindle speed |
(12)60-1750r.p.m(V).(12)60-1800r.p.m(H) |
Swivel angle of swivel head |
360degrees |
Workbench maximum turning around |
45 degrees |
Table size |
1600x360mm |
Table travel(horizontal/cross/vertical) |
1000/340/450mm |
Range of longitudinal travel |
(8steps)30-630mm/min(max2000) |
Range of cross travel |
(8steps)30-630mm/min(max2000) |
Range of vertical travel |
(8steps)18-300mm/min (max630) |
T-slot NO./width/distance of table |
3/18/80mm |
Main motor |
4.0kw (V)4.0KW(H) |
Motor for rapid devtce of table |
1500w |
Motor for vertical devtce of table |
1500w |
Motor of cooling pumps |
120w |
Speed of cooling pumps |
25L/min |
Max weight of workpiece |
600kg |
Overall dimension |
2120x2000x2250mm |
N.W/C.W |
2650/2850kg |
Detailed Images
Related Products
Packing&Shipping
Company Profile
Professional Service
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
