Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Z3080X25 Hydraulic Heavy Radial Drilling Machine With CE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Clamping Z3040/12 Cheap Radial Drilling MachineNegotiableMOQ: 1 -
Table Milling Machine Manual Mills X6325W Vertical Turret Milling Machine With Factory PriceNegotiableMOQ: 1
-
XU28 XU32 Vertical Horizontal Universal Milling Machine With CENegotiableMOQ: 1
-
ZX32G Dia.32mm Manual Milling Machine for Metal WorkingNegotiableMOQ: 1
-
ZAY7045V Variable Speed Milling Drilling Machine for Sale From ChinaNegotiableMOQ: 1
Features:
1.Radial drilling machine
2.Transmission:Mechanical transmission
3.Max. drilling diameter:80mm
4.Spindle taper:Morse 6
5.Spindle travel:400mm
Specification:
Technical parameters | Z3080×25 |
Max Drilling Diameter(mm) | 80 |
Spindle center to column (mm) | 480-2500 |
Spindle nose to table (mm) | 350--1570 |
Spindle travel (mm) | 400 |
Spindle taper(Morse) | 6 |
Spindle speed range (r/min) | 16--1600 |
Spindle speeds series(mm/r) | 0.04-3.2 |
Radial rotation Angle | 180° |
Main motor power( kw) | 7.5 |
Lifting Motor Power ( kw) | 1.5 |
Machine weight (kgs) | 9500 |
Machine overall size (L*W*H mm) | 3500×1450×3300 |
