Hydraulic Clamping Z3040/12 Cheap Radial Drilling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Table Milling Machine Manual Mills X6325W Vertical Turret Milling Machine With Factory PriceNegotiableMOQ: 1 -
XU28 XU32 Vertical Horizontal Universal Milling Machine With CENegotiableMOQ: 1
-
ZX32G Dia.32mm Manual Milling Machine for Metal WorkingNegotiableMOQ: 1
-
ZAY7045V Variable Speed Milling Drilling Machine for Sale From ChinaNegotiableMOQ: 1
-
WMT Vertical Type Mill Machinery X6332B Universal Milling MachineNegotiableMOQ: 1
Features:
Radial drilling machine is provided with hydraulic presetting speed shift mechanism to save auxiliary time.
It only needs one handle to operate clockwise rotation, stop (brake), variable speed and neutral gear conveniently.
Spindle box, rocker arm, inner and outer posts are reliably clamped by hydraulic diamond clamping mechanism.
Perfect safety protector and outer post protection are available.
In design and production of structure, it further adopts a series of effective measures to prolong precision durability and lifespan of whole machine.
Its electrical equipment completely contributes to personal safety, reliability, long service life and convenient maintenance.
Model |
Z3040/12 |
Z3040/14 |
|
Max drilling capacity |
40mm |
||
Distance from spindle nose to column |
300-1200/1400mm |
||
Spindle horizontal travel |
900/1100mm |
||
Spindle vertical travel |
300-1240mm |
||
Spindle taper |
MT4 |
||
Spindle travel |
210mm |
||
Radial arm lifting speed |
1.26m/min |
||
Radial arm lifting distance |
650mm |
||
Drilling depth per circle |
140mm |
||
Spindle speed |
80-1200r/min |
||
Spindle speed series |
6 |
||
Range of spindle feed |
0.10-0.30mm/r |
||
Spindle feed series |
3 |
||
Main motor power |
1.5kw |
||
Lifting motor power |
0.75kw |
||
Hydraulic clamping motor power |
0.55kw |
||
Coolant pump power |
40w |
||
Table size |
550x350x350mm |
||
Net weight |
1500kgs/1700kgs |
||
Oversall size |
1700/1900x800x2200mm |
||
