Table Milling Machine Manual Mills X6325W Vertical Turret Milling Machine With Factory Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XU28 XU32 Vertical Horizontal Universal Milling Machine With CENegotiableMOQ: 1 -
ZX32G Dia.32mm Manual Milling Machine for Metal WorkingNegotiableMOQ: 1
-
ZAY7045V Variable Speed Milling Drilling Machine for Sale From ChinaNegotiableMOQ: 1
-
WMT Vertical Type Mill Machinery X6332B Universal Milling MachineNegotiableMOQ: 1
-
Universal Vertical Milling Machine XZ6350ZB for Metal WorkingNegotiableMOQ: 1
Product Description
Table milling machine manual mills X6325W vertical turret milling machine
Universal MIlling Machine Main Features:
1. Universal milling machine;
2. Vertical milling variable speed;
3. X/Y axis auto feeding.
Specification | Unit | X6325W | X6330W |
Table size | mm | 1270X254 | 1370x305 |
T slot | 3/16/65 | 3/16/65 | |
Longitudinal travel | mm | 750(850manually) | 800 |
Cross travel | mm | 400 | 380 |
Vertical travel | mm | 400 | 360 |
Quill travel | mm | 127 | 127 |
Spinedle and Column distance | mm | 155-635 | 155-635 |
Spindle and table distance | mm | 0-640 | 0-460 |
Arm travel | mm | 400 | 500 |
Milling head tilting | degree | 90(left right)45(front back) | 90(left right)45(front back) |
Spindle taper | R8(V);NT80(H) | R8(V);NT80(H) | |
Spindle speed | r/min | 66-4540(V);40-1300(H) | 66-4540(V);40-1300(H) |
Spindle motor power | kw | 2.2(V);3(H) | 2.2(V);3(H) |
Table load | kg | 350 | 350 |
Overall size | mm | 1750x1530x2340 | 1750x1650x2340 |
Net weight | kg | 1380 | 1550 |
Machine pics.
You may find the accessories that you like:
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
