Universal Vertical Milling Machine XZ6350ZB for Metal Working
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZAY7045V Variable Speed Small Milling Machine for Metal WorkingNegotiableMOQ: 1 -
Ram Milling Machine Universal Milling Machine X5750 With CE Certificate and Good PriceNegotiableMOQ: 1
-
Vertical Type Mill Machinery X7140S Bed Type Milling MachineNegotiableMOQ: 1
-
4H Variable Speed Universal Milling Machine With China PriceNegotiableMOQ: 1
-
5H Cheap Vertical Type Mill Machine With Factory PriceNegotiableMOQ: 1
Features:
Headstock swivels ±90º
XZ6350ZB vertical milling spindle auto-feeding. X/Y/Z axis auto feeding.
Specification details:
Specification | XZ6350ZB |
Worktable size | 1270×280mm |
Spindle taper | ISO40 |
Distance fromspindle to table | 90-470mm |
Distance from horizontal spindle to table | 0-380mm |
Distance from spindle to column | 200-550mm |
Spindle speed | 8 steps vertical:90-2000rpm,12 steps horizontal:40-1300rpm |
Spindle travel | 127mm/r |
Feeding of quill | 3 steps:0.04,0.08,0.15 |
Head movement(left/right) | ±90° |
Max. drilling capacity of auto-feeding | 15(iron) |
Table travel(horizontal/cross/vertical) | 750/300/380mm |
Distance from spindle axis to arm | 200mm |
Feeding range of longitudinal and cross travel | 8 steps:22-555 (fast feeding 1080mm/min) |
Auto-feeding of Z-axis | 560mm/min |
T-slot (No./width/distance) | 3-14-70 |
Main motor(vertical/horizontal) | 2.25/2.2KW |
Motor power for X/Y auto-feeding | 750W |
Motor power for Z auto-feeding | 750W |
Oversal size of machine | 1700×1670×2300mm |
Neight weight/Gross weight | 1660/1760kg |
You may find the accessories as you like:
Details about the package:
