C6253 Big Manual Lathe Machine Engine Lathe for Metal Cutting
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CQ6280Cx2000 3000 China Metal Manual Engine Lathe Machine for SaleNegotiableMOQ: 1 -
CD6240B 400mm Max.swing Over Bed Manual Metal Lathe Machine Manufacturer Directly SellNegotiableMOQ: 1
-
Pipe Thread Lathe Q1325 Manual Pipe Threading Metal Lathe MachineNegotiableMOQ: 1
-
1000mm C6250C 52mm Spindle Metal Manual Lathe Machine Price for SaleNegotiableMOQ: 1
-
2022 New Small Manual Lathe Benchtop Lathe Machining CJM0632V Metal Lathe Machine With Variable SpeedNegotiableMOQ: 1
Product Description
Big manual lathe engine lathe machine C6253 X1500 2000 3000mm main features:
1. Big spindle bore: 82mm;
2. Bed width: 400mm;
3. Max. swing over bed: 530mm.
Model |
C6253×1000 |
C6253×1500 |
C6253×2000 |
||
Swing over bed |
Φ530mm(20 7/8") |
||||
Swing over cross slide |
Φ329mm(12 31/32") |
||||
Swing in gap(D×W) |
765mm×218mm(D1-8)/765mm×240mm(A1-8) |
||||
Height of center |
265mm(10 7/16") |
||||
Distance between centers |
1015mm/1515mm/2015mm |
||||
Width of bed |
400mm(15 3/4") |
||||
Max. section of cutting tool |
25mm×25mm(1"×1") |
||||
Total travel of cross slide |
320mm(12 5/8") |
||||
Total travel of top slide |
200mm(7 7/8") |
||||
Spindle bore |
Φ82mm(3 1/4") |
||||
Spindle nose |
D1-8 or A1-8 |
||||
Spindle morse taper in nose,in sleeve |
ME90/M.T.#5 |
||||
Spindle speeds number |
12 |
||||
Spindle speeds range |
20-1600 R.P.M |
||||
Leadscrew diameter&thread |
40mm(1 9/16")×4 T.P.I or pitch 6mm |
||||
Threads imperial pithches |
4-112(50 NOS) |
||||
Threads metric pithches |
0.25-7(24 NOS) |
||||
Diametral pitches DP/DP |
4-112(50 NOS) |
||||
Diametral pitches MP/MP |
0.25-14(34 NOS) |
||||
Longitudinal feeds(imperial/metric) |
0.0011"-0.0316"(50Nos)/0.01mm-0.286mm(50Nos) |
||||
Cross feeds(imperial/metric) |
0.00024"-0.0068"(50Nos)/0.01mm-0.286mm(50Nos) |
||||
Total travel of tailstock quill |
180mm(7 5/64") |
||||
Tails stock quill |
Φ75mm(2 61/64") |
||||
Taper tailstock quill |
M.T.#5 |
||||
Spindle drive motor |
10.0HP |
||||
Coolant pump motor |
1/8HP(0.1KW) |
||||
Machine dimension |
94"×38"×52"/114"×38"×52"/134"×38"×52" |
||||
Packing dimension |
98"×43"×71"/118"×43"×71"/138"×43"×71" |
||||
N.W |
2490KG/2750KG/3010KG |
||||
G.W |
2790KG/3090KG/3400KG |
||||
Detailed Images
Standard accessories:
3 Jaw chuck
82 mm big spindle bore
4 jaw chuck
Steady rest
Follow rest
Change gears
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
