Home > Auto, Motorcycle Parts & Accessories > Auto Engine Structure > Ignition System > CQ6280Cx2000 3000 China Metal Manual Engine Lathe Machine for Sale
CQ6280Cx2000 3000 China Metal Manual Engine Lathe Machine for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CD6240B 400mm Max.swing Over Bed Manual Metal Lathe Machine Manufacturer Directly SellNegotiableMOQ: 1 -
Pipe Thread Lathe Q1325 Manual Pipe Threading Metal Lathe MachineNegotiableMOQ: 1
-
1000mm C6250C 52mm Spindle Metal Manual Lathe Machine Price for SaleNegotiableMOQ: 1
-
2022 New Small Manual Lathe Benchtop Lathe Machining CJM0632V Metal Lathe Machine With Variable SpeedNegotiableMOQ: 1
-
Economic Multi-purpose Lathe Machine MPV280 Combo Lathe and Milling Drilling Machine in ChinaNegotiableMOQ: 1
Product Description
CQ6280C manual lathe machine Features:
1. Perform internal and external turning, taper turning, end facing, and other rotary parts turning; Engine lathe
2. Threading Inch, Metric, Module and D.P.;
3. Perform drilling, boring and groove broaching;
4. Respectively with through-hole spindle bore, that can hold bar stocks in larger diameters;
5. Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring systems countries;
6. There are hand brake and foot brake for users to choose;
7. Power supply of different voltages (220V/380V/420V) and different frequencies (50Hz, 60Hz) are available.
Main Technical Data
Specification |
Unit |
CQ6280C |
Max swing over bed |
mm |
Φ800 |
Max swing in gap |
mm |
Φ1000 |
Effective length in gap |
mm |
240 |
Max swing over slide |
mm |
Φ560 |
Max workpiece length |
mm |
2000/3000 |
Spindle thru-hole |
mm |
Φ105 |
Spindle nose |
ISO 702/2 No.8 cam-lock type |
|
Spindle speed |
r/min |
12 step 30-1400 |
Spindle motor |
kW |
7.5 |
Quill dia./travel |
mm |
Φ90/150 |
Taper of center |
MT |
5 |
Number of station/ |
4/25X25 |
|
Tool section |
||
Max X-axis travel |
mm |
145 |
Max Z-axis travel |
m/min |
320 |
X-axis feed |
mm/r |
65 sorts 0.063-2.52 |
Z-axis feed Z-axis feed |
mm/r |
65 sorts 0.027-1.07 |
Metric thread |
mm |
22 sorts 1-14 |
Inch thread |
t.p.i |
25 sorts 28-2 |
Module thread |
πmm |
18 sorts 0.5-7 |
DP thread |
t.p.i. π |
24 sorts 56-4 |
Coolant pump motor |
kW |
0.06 |
Machine length |
mm |
3365/4365 |
Machine width |
mm |
1340 |
Machine height |
mm |
1490 |
Machine weight |
kg |
3300/3700 |
Detailed Images
Products Recommend
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
