CD6240B 400mm Max.swing Over Bed Manual Metal Lathe Machine Manufacturer Directly Sell
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Pipe Thread Lathe Q1325 Manual Pipe Threading Metal Lathe Machine
-
1000mm C6250C 52mm Spindle Metal Manual Lathe Machine Price for Sale
-
2022 New Small Manual Lathe Benchtop Lathe Machining CJM0632V Metal Lathe Machine With Variable Speed
-
Economic Multi-purpose Lathe Machine MPV280 Combo Lathe and Milling Drilling Machine in China
-
New Design 1500mm CM6241 Manual China Engine Lathe Machine With DRO for Metalworking
-
WMTCNC Variable Speed MPV290 Combination Lathe Milling Machine With 220V/50HZ/single-phase
Product Description
Product Description
China Metal Manual Engine Lathe Main Features:
1. Super voice frequency heated bedways;
2. Hardened and grounded gears in the headstock;
3. With 2 precision D degree taper roller bearings on the spindle;
4. Integrated deluxe cast iron floor stand;
5. Tolerance test certificate, test flow chart included.
Specification | CD6240B/C |
Max.swing over bed | Φ400mm |
Max.swing over cross slide | Φ225mm |
Max.swing over gap | Φ550mm |
Effective length of gap | 260mm |
Center Distance | 1000mm/1500mm/2000mm/3000mm |
Bed Width | 330mm |
Spindle hole | B:Φ65mm,C: Φ80mm |
Spindle nose | B:ISO-D6,C:ISO-D8 |
Spindle speed(Number) | B:20-1800rpm(15steps) C:/24-1600rpm(15steps) |
Longitudinal feeds range | 66kinds 0.072-4.038mm/rev(0.0027-0.15inch/rev) |
Cross feeds range | 66kinds 0.036-2.019mm/rev(0.0013-0.075inch/rev) |
Metric threads range | 66kinds 0.5-28 |
Inch threads range | 66kinds 1-56inch |
Module threads range | 33kinds 0.5-3.5mπ |
Diametric threads range | 33kinds 8-56D.P |
Max.travel of top slide | 130mm |
Max.travel of cross slide | 300mm |
Max.size of tool shank | 20×20mm/25×25mm |
Dia.of tailstock sleeve | Φ65mm |
Taper of tailstock sleeve | MT5 |
Max.travel of tailstock | 120mm |
Main drive motor | 5.5kw or 7.5kw |
Rapid traverse motor | 250w |
Coolant pump motor | 125w |
Packing size | 1000mm:2420mm×1150mm×1800mm 1500mm:2920mm×1150mm×1800mm 2000mm:3460mm×1150mm×1800mm 3000mm:4720mm×1150mm×1800mm |
N.W/G.W | 1000mm:1560/2210kgs 1600/2250kgs 1640/2290kgs |
1500mm:1770/2410kgs 1830/2470kgs 1870/2530kgs | |
2000mm:2010/2780kgs 2070/2820kgs 2130/2860kgs |
Detailed Images
Company Profile
Professional Service
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
Company Profile
Jingjiang Fuji Technology Co., Ltd.
Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
