Home > Auto, Motorcycle Parts & Accessories > Auto Engine Structure > Ignition System > Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking thumbnail-3

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking thumbnail-4

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking photo-1

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking photo-2

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking photo-3

Fanuc Cnc Lathe CK0640 Benchtop Cnc Lathe Machine for Metalworking photo-4

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

CK0640 High Precision Mini CNC Lathe:

1. CK0640 can be permanently memory coordinates after power offer, you do not need worry if people moved the position; it can continuely Processing half of the workpiece.

2. Machine often caused alarms because of these widgets, CK0640 can set soft limit,so that can save machine maintenance time and cost.

3. High precision, CK0640 use Absolute servo encoder is 17 bits.

4. It is suitbale for mass production for small workpiece, high efficiency, high precision.

Specification	CK0640
Max.swing over bed	260mm
Diameter of X axis ballscrew	25mm
Thread pitch of X axis ballscrew	4mm
Diameter of Z axis ballscrew	32mm
Thread pitch of Z axis ballscrew	6mm
X-axis travel	250mm
Z-axis travel	180mm
Max speed	2200rpm
Pneumatic component	Taiwan AIRTAC
chuck	Pneumatic chuck 32mm
toolpost	4 position Electrical toolpost
Main Motor	3KW
Spindle converter	VEICHI
Motor for Coolant pump	90W
Spindle bore	49mm
Spindle hole after install pneumatic	41.5mm
Re-positioning accuracy	0.01mm
positioning accuracy	0.01mm
Servo motor torque	4.0NM
Servo motor type	Servo motor
CNC controller system	GSK, Siemens 808DA, After 980MDC Available
Button switch	Led Metal switch
Machine size	176010701730
N.W/G.W	700KGS/800KGS

Detailed Images

Company Profile

Professional Service

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?

A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?

A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?

A4: One set only.

Q5: How about your quality?

A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?

A6: Yes.we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?

A7: Yes, we can design and manufacture according to your specific requirements.
