BNUV-S640 BNUV-S650 UV Visible Spectrophotometer With 4nm and 2nm Spectral Bandwidth
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BNUV-R720 Split Beam UV Visible SpectrophotometerNegotiableMOQ: 1 -
BNUV-R770 BNUV-R780 Split Beam UV Visible SpectrophotometerNegotiableMOQ: 1
-
BNUV-D800 Double Beam Scanning UV Visible SpectrophotometerNegotiableMOQ: 1
-
BNUV-D830 BNUV-D840 BNUV-D850 Double Beam Scanning UV Visible SpectrophotometerNegotiableMOQ: 1
-
BNUV-D860 BNUV-D870 BNUV-D880 Double Beam Scanning UV Visible SpectrophotometerNegotiableMOQ: 1
Product Description
Product features:
Photometric measurement: one key switch A/T/E
Quantitative measurement: establish standard curve
File management: data preservation, editable fifile name
Performance verifification: verififiable performance speci-
fifications
System application: Multilingual operating system
Dismountable lamp room cover, can change lamp easily
Data can be export from the U disk with .CSV and .TXT format
Support general printer with A4 paper printing
The front baffle of the sample room can be dismantled freely
Special leak hole in the sample room
Antirust treatment cell holder
Quantitative measurement: establish standard curve
File management: data preservation, editable fifile name
Performance verifification: verififiable performance speci-
fifications
System application: Multilingual operating system
Dismountable lamp room cover, can change lamp easily
Data can be export from the U disk with .CSV and .TXT format
Support general printer with A4 paper printing
The front baffle of the sample room can be dismantled freely
Special leak hole in the sample room
Antirust treatment cell holder
Product Paramenters
Model |
BNUV-S640 |
BNUV-S650 |
|
Optical system |
Single beam，1200 l/mm grating |
||
Wavelength range |
190~1100 nm |
||
Spectral bandwidth |
4 nm |
2 nm |
|
Wavelength accuracy |
±0.5 nm |
||
Wavelength repeatability |
≤0.2 nm |
||
Wavelength resolution |
0.1 nm |
||
Wavelength swing speed |
6000 nm/s |
||
Wavelength scanning speed |
25~4200 nm/s |
||
Photometric range |
-0.3~3 A，0~200 %T，0~9999.9 C |
||
Photometric accuracy |
±0.002A（0~0.5 A），±0.004 A（0.5~1 A）, ±0.5 %T（0~100 %T） |
||
Photometric repeatability |
±0.001 A（0~0.5 A），±0.002 A（0.5~1 A）, ±0.2 %T（0~100 %T） |
||
Photometric Noise |
≤0.0005 A @ 0 A，500 nm，≤0.001 A @ 1 A，500 nm，≤0.002 A @ 2 A，500 nm |
||
Photometric Stability |
≤0.002A/hr (500nm, 2 hours after preheating) |
||
Stray light |
≤0.05 %T（220 nm, 360 nm） |
||
Baseline |
±0.002A |
||
Function |
Photometric, Quantitation, Spectrum, File management, system management, Performance vertification |
||
Light source |
Tungsten lamp, Deuterium lamp |
||
Detector |
Silicon photodiode |
||
Standard Sample holder |
10 mm 4-cell manual holder |
||
Display |
5 inch TFT color touch screen |
||
Storage |
236 KB (built-in), supports unlimited external expansion (USB memory) |
||
Interface |
RS232 serial port × 1 (printer), USB-A × 1 (USB memory/USB printer), USB-B × 1 (computer) |
||
PC software |
Optional |
||
Language |
6 Languages, Can Be Switched (English, German. French, Spanish, Portuguese. Simplified Chinese) |
||
Power supply |
AC 100~240 V，50/60 Hz，120W |
||
Size |
456（W）×360（D）×185（H） mm |
||
Weight |
10.7 kg |
||
