BNUV-D800 Double Beam Scanning UV Visible Spectrophotometer

BNUV-D800 Double Beam Scanning UV Visible Spectrophotometer thumbnail-1
BNUV-D800 Double Beam Scanning UV Visible Spectrophotometer thumbnail-2
BNUV-D800 Double Beam Scanning UV Visible Spectrophotometer photo-1
BNUV-D800 Double Beam Scanning UV Visible Spectrophotometer photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Hangzhou Boyn Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
Product features: Double beam optical system
8-inch color touch-screen
Automatic zero and full scale adjustment
Automatic wavelength settings
Equipped with USB COM port
Sophisticated power protection system
Thermal plotter optional
Product Paramenters
Model
BNUV-D800
BNUV-D810
BNUV-D820
Photometry
Double Beam, Grating 1200 lines/mm
Double Beam, Grating 1600 lines/mm
Wavelength Range
190-1100nm
Spectrum Bandwidth
1.8nm
1nm
0.5/1/2/4/5nm
Auto Adjustable
Wavelength Accuracy
±0.5nm
±0.3nm
Wavelength Repeatability
≤0.2nm
≤0.1nm
Photometric Range
0.0-200.0%T
-0.301-4.000A
0.000-9999C
Photometric Accuracy
±0.3%T
±0.002Abs (0-0.5A)
±0.004 Abs (0.5-1A)
Photometric Repeatability
≤0.15%T
0.001 Abs (0-0.5A)
0.002 Abs (0.5-1A)
Scanning Speed
Fast-Medium-Slow
Baseline
≤±0.002A (200-1090nm)
≤±0.0008 A(200-1090nm)
Stray Light
≤0.03%T( at 220nm NaI, 360nm NaNo2 )
≤0.02%T( at 220nm NaI, 360nm NaNo2 )
Noise
100%（T）noise≤0.15%(T) ，
0%（T）noise≤0.1%(T)
100%（T）noise≤0.1%(T) ， 0%（T）noise≤0.02%(T)
Drifting
≤0.0009 Abs/30min (250nm and
500nm after 2h warm up)
≤0.004 Abs/h (250nm and 500nm after 2h warm up)
Display
8-inch color touch-screen
Measuring function
Full-spectrum scanning, Linear regression, Detailed spectrum scanning, Concentration
direct reading, Time-based kinetics determination, Peak / Valley detecting, GOTO λ,
Multi-wavelength measurement
Monochromator Type
Czerny-Turner
Focal Length
160mm
200mm
Detector
Silicon Photocell
Light Source
Tungsten lamp, Deuterium lamp
Wavelength Setting
Auto
Standard cell Holder
one position 10mm cell holder
two positions 10mm cell holder
Sample compartment
10mm pathlength cuvette
Output Interface
USB port
PC software
It's optional
Power
AC220V 50Hz 200W
Packaging Size
710×590×505mm
730×630×450mm
G.W.
36kg
42.5kg
Standard Accessories
Glass cuvette 10mm×4, Quartz cuvette 10mm×2,Fuse×2, Power cable, User manual
