Electric lifting 50L vacuum rotary evaporator for distillation

Name: Electric lifting 50L vacuum rotary evaporator for distillation
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Electric lifting 50L vacuum rotary evaporator for distillation

Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting, revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad.
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display

Specification

Model	NBRE-50L	NBRE-100L
Glass meterial	GG-17	GG-17
Holder material	Stainless steel	Stainless steel
Pot shell Material	Spray anti-corrosion 710620700mm	Spray anti-corrosion 820*820mm
Pot bravery	Stainless steel 550*320mm	Stainless steel 795*330mm
Plate size	804*574mm	1600*830mm
Evaporator flask	50L flange mouth:Φ125mm	100L flange mouth:Φ180mm
Collect flask	20L flange mouth:Φ60mm	50L ball mouth:Φ40mm
Vacuum degree	0.098Mpa	0.098Mpa
Rotary speed	0-110RPM	0-110RPM
Rotary power	180W 220V/50HZ	400W 220V/50HZ
Heating power	8KW 380V/50HZ	12KW 380V/50HZ
Heating temp.	0-400℃	0-400℃
Temp. accuracy	±1℃	±1℃
Lifting stroke	180mm	180mm
Dimension	15206202470mm	17008502600mm
Packing weight	170kg	400kg

If You Need Other Model, Please Contact Us To Get More Information

More Details Photos

Application

Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration .
