New type high quality glass laboratory auto explosion proof rotary evaporator 10 20 30 50 Liter
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Chemical Lab Evaporation Equipment rotary distiller vacuum rotary evaporator
-
50L chemistry Vacuum Rotary Evaporator Concentrator with supporting Chiller and Vacuum Pump
-
1L Small laboratory distillation equipment rotary evaporator with vacuum pump & chiller
-
Small volume china digital rotary evaporator with vacuum pump and chiller for industry distillation
-
China Lab short path distillation mini vacuum rotary evaporator equipment with chiller and vacuum pump
-
CE High efficiency laboratory vacuum rotary evaporator machine with supporting chiller and pump
Product Description
Product Description
New type laboratory Auto Rotary Evaporator(Rotary) 10 20 30 50 Liter
Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting, revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad.
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display
Specification
Model | NBRE-50L | NBRE-100L |
Glass meterial | GG-17 | GG-17 |
Holder material | Stainless steel | Stainless steel |
Pot shell Material | Spray anti-corrosion 710*620*700mm | Spray anti-corrosion 820*820mm |
Pot bravery | Stainless steel 550*320mm | Stainless steel 795*330mm |
Plate size | 804*574mm | 1600*830mm |
Evaporator flask | 50L flange mouth:Φ125mm | 100L flange mouth:Φ180mm |
Collect flask | 20L flange mouth:Φ60mm | 50L ball mouth:Φ40mm |
Vacuum degree | 0.098Mpa | 0.098Mpa |
Rotary speed | 0-110RPM | 0-110RPM |
Rotary power | 180W 220V/50HZ | 400W 220V/50HZ |
Heating power | 8KW 380V/50HZ | 12KW 380V/50HZ |
Heating temp. | 0-400℃ | 0-400℃ |
Temp. accuracy | ±1℃ | ±1℃ |
Lifting stroke | 180mm | 180mm |
Dimension | 1520*620*2470mm | 1700*850*2600mm |
Packing weight | 170kg | 400kg |
If You Need Other Model, Please Contact Us To Get More Information
More Details Photos
Application
Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration .
