24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products

24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products photo-1
24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products photo-2
24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products photo-3
24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products photo-4
24V 1A AC DC Adaptor Wallmount EU AC Plug With CE Approve 24V Switching Power Supply For LED CCTV Camer Digital Products photo-5
US$ 3.65 - 3.98 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
JNORTY
Place of Origin:
China
Model Number:
JDTA36E-240100
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
15 days
Brand Name JNORTY
Place of Origin China
Model Number JDTA36E-240100
Connection Plug In
Output Type DC

30W  EU AC Plug  Switching Power Supply

Specification Parameter:
1,Input condition:
     Rated input voltage: 100V-240Vac
     Input voltage range: 90V-264Vac
     Rated input frequency: 50/60Hz  +/-3Hz


2,Output Characteristics:
     Rated output power: 24W-36W Series
     Output voltage range: 5.0-30Vdc
     Output voltage error range: +/-5%
     Output current range: 0.1-4.0A

3,Protection Function:
    (1). Short-circuit current protection;
    (2). Overvoltage protection;
    (3) .Overcurrent protection;

4,Environment Requirements:
     Operating Temperature: 0ºC to +40ºC
     Operating Relative Humidity: 0%RH to 90%RH
     Storage Temperature: -20ºC to +80ºC
     Storage Relative Humidity: 5%RH to 95%RH non-condensing

5,Product Features:
    (1). High temperature fire resistant and flame retardant shell material is used.
    (2). Voltage stabilization mode;
    (3). IC electric design, stable performance, safe and reliable;
    (4). High efficiency, low no-load power consumption, energy saving and environmental protection;

6.Apply to:

   Lighting, toys,motors,fans,CCTV camera, electronics products....

7,specification parameter:

Parameter:
Input/Output Input:AC100-240V 50/60Hz 0.8A
Output:DC5V-30V / 0.1A-4A  24W-36W (Max)
safety certificate: PSE CB CCC CE UKCA
Output  Voltage
(V)
5.0V 6.0V 8.0V 9.0V
9.6V
10V 12.0V
12.6V
14V 15V 16V 18V 19V 20V 24V 25V
25.2V
26V 28V 29.5V 30V
Current  Output
(A)
3.5A
4.0A
3.5A
4.0A
2.5A
3.0A
2.5A

2.6A

3.0A

2.4A

2.5A

3.0A

2.0A

2.5A

3.0A

1.7A
2.0A
2.4A
1.6A
2.0A
2.4A
1.5A
1.87A
2.25A
1.33A
1.6A
2.0A
1.26A
1.57A
1.89A
1.2A
1.5A
1.8A
1.0A
1.25A
1.5A
1.0A
1.2A
1.42A
0.9A
1.0A
1.38A
0.85A
1.0A
1.28A
0.8A
1.0A
1.2A
0.8A
1.0A
1.2A

8. Safety Certificate:

9.  Introduction of the factory:


Product Tags: 24V AC DC Adapter , 24V Switching Power Supply , CCTV Power Adaptor
