12V 3A LED Switching Power Supply With PSE Certificate 12V3A AC DC Adaptor for CCTV LED Camera Motor Smart Home

36W  Japan AC Plug  Switching Power Supply

Specification Parameter:
1,Input condition:
     Rated input voltage: 100V-240Vac
     Input voltage range: 90V-264Vac
     Rated input frequency: 50/60Hz  +/-3Hz


2,Output Characteristics:
     Rated output power: 36W Series
     Output voltage range: 9-30Vdc
     Output voltage error range: +/-5%
     Output current range: 0.1A-3A

3,Protection Function:
    (1). Short-circuit current protection;
    (2). Overvoltage protection;
    (3) .Overcurrent protection;

4,Environment Requirements:
     Operating Temperature: 0ºC to +40ºC
     Operating Relative Humidity: 0%RH to 90%RH
     Storage Temperature: -20ºC to +80ºC
     Storage Relative Humidity: 5%RH to 95%RH non-condensing

5,Product Features:
    (1). High temperature fire resistant and flame retardant shell material is used.
    (2). Voltage stabilization mode;
    (3). IC electric design, stable performance, safe and reliable;
    (4). High efficiency, low no-load power consumption, energy saving and environmental protection;

6.Apply to:

   Lighting, toys,motors,fans,CCTV camera, electronics products....

7,specification parameter:

8. Safety Certificate:

9.  Introduction of the factory:
