40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters

40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters thumbnail-1
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters thumbnail-2
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters thumbnail-3
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters thumbnail-4
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters photo-1
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters photo-2
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters photo-3
40g 3.5mm Female to 2.92mm Male RF Coxial Connector Adapters photo-4
US$ 0.23 - 1.1 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
ROHO
Place of Origin:
China
Model Number:
N Type Female Connector
Contact Supplier Request Quote Chat Now
Roho Connector Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ROHO
Place of Origin China
Model Number N Type Female Connector
Type Adapter
Application RF
Gender Male

2.92/2.4Precision coaxial connector for microwave applications. The maximum frequency is
40GHz.
Design in accordance with: IEEE287™ -2007
Standard materials and finish
Center conductor Beryllium copper, gold plated
Insulator PEI
Outer conductor Stainless steel, Passivated


Electrical Characteristics
Characteristic Impedance 50Ω
Frequency range DC-40GHz
VSWR 1.15: 1 max
Insulation resistance 5000MΩ Min
Test voltage 1000V




Mechanical
Coupling torque 1.69N*m max
Mating cycles 1000cycles min
Environmental
Temperature range: -55° C~+155° C


Product Tags: RF Connectors , Coaxial Cable Connector , 40g 3.5mm to 2.92mm RF Cable Connector , RF Coaxial Connector Adaters , SMA to N RF Coaxial Connectors for Cable , N to DIN RF Coaxial Adapters , Coaxial Cable Connectors , 4.3/10 to N Connector Adapter , Wire Connector
