Home > Products > pneumatic drilling rig > FY300 crawler pneumatic water well drilling rig / crawler mounted water well drilling machine factory direct sale
FY300 crawler pneumatic water well drilling rig / crawler mounted water well drilling machine factory direct sale
- 50 Set / Sets per Month
- Qingdao
- T/T L/C
- 10 days
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Brand Name: | HuaxiaMaster | Place of Origin: | China | Model Number: | FY300 |
| Type: | Rotary Drilling Rig | Certification: | ISO 9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | 6 Months | Weight: | 8.8T | Dimension(L*W*H): | 4350*1850*2750MM |
| Power Type: | Diesel | Voltage: | no | Usage: | Water Well |
| Condition: | New | Power(W): | 85KW |
Product Description
1.The range of application of FY300 crawler type gas drilling rig
Applicable to civil engineering drilling, geothermal drilling, drilling with large diameter and deep drilling footage, it’s fast, flexible and efficient.
2.The technical parameter ofFY300 crawler type gas drilling rig
Model | FY300 | |
Gross weight | t | 8.8 |
External dimension | mm | 4350*1850*2750 |
Aperture | mm | 140-325 |
Drilling depth | m | 300 |
Feed stroke | mm | 6000 |
Travel speed | km/h | 2 |
Grade ability | max. | 30° |
Rising height from ground | mm | 230 |
Wind pressure | mpa | 1.7-3.3 |
Air consumption | m³/min | 23 |
Engine power | kw | 85 |
Rotary speed | rpm | 55-115 |
Rotation torque | n.m | 7200-8500 |
