General introduction
1. Usage: for radiography & fluoroscopy
2. The unit is a shockproof, scatter-proof, single-focus, full wave silicon rectified mobile diagnosis X-ray apparatus.
3. The X-ray generator is knockdown, and the whole unit is deft can be moved into ward.
4. A wireless remote controller (control range ≥5m) is used to prevent personnel contacting the scatter radial. It has high stability and strong anti-jamming capability.
Technical parameters
1. Power supply:voltage:180~240V(single phase) Frequency:50Hz
Current:fluoroscopy 3A ( continuous ) radiography 16A ( instantaneous )
Internal resistance of power cord ≤0.4Ω.
2. Descriptions of loading factors:
Max. KV:85kV; Max. mA:30mA; Max. rated capacity:85kVp,30mA,8s
Max. output power:continuous mode: P=0.74×85kV×5mA=0.314kw;
Intermittent mode: P=0.74×85 kV×30mA=1.88kw
Nominal electric power:85kVp,30mA,8s; P=0.74×85 kV×30mA=1.88kw
3. Voltage of x-ray tube:50~85kV 8 steps
Current of x-ray tube ( continuous mode ) 0~5mA continuously adjustable
Intermittent mode:15mA 30 mA 2 steps time:0.10~8.0 s
4. Operation mode:Intermittent load continuous operation
Packing datas
| Gross weight | 164kg |
| N.W. | 98kg |
| Packing dimension | 88 cm*165cm*59cm 0.86m³ |
Strong Plywood Case
Certificate&Warranty&service
CE, ISO13485;
12 months from the date of shipment;
Best after-sale service, technical support forever.
Mobile types suitable for veterinary
50mA mobile x-ray model SF50BY with CE, FSC, ISO certificate;
70mA mobile x-ray model SF70BY with CE, FSC, ISO certificate;
100mA mobile x-ray model SF100BY with CE, FSC, ISO certificate.
