Testing Machine Manufacturer Material Testing Machine Tensile Tester

Testing Machine Manufacturer Material Testing Machine Tensile Tester photo-1
Testing Machine Manufacturer Material Testing Machine Tensile Tester photo-2
Testing Machine Manufacturer Material Testing Machine Tensile Tester photo-3
Testing Machine Manufacturer Material Testing Machine Tensile Tester photo-4
Testing Machine Manufacturer Material Testing Machine Tensile Tester photo-5
US$ 38000 - 120000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
GOPOINT
Place of Origin:
China
Model Number:
GP-TS2000L/D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
60 days
Brand Name GOPOINT
Place of Origin China
Model Number GP-TS2000L/D
Power Electronic
Usage Universal Testing Machine

Electronic   universal tester Applicable   for wide range of metal Non-metallic material for tension,bending,   shearing,Stripping,Tear Mechanical properties test.With special fixtures, the   use of parts can be tested .according to GB,JIS,ASTM,DM,ISO etc standard   Automatically display mix number of test. Breaking force ,up  down Yield Strength,tensile   strength,Various Elongation stress,Elongation,Compressive strength,Bend   deflection,Elastic Modulus etc. Equipped with a special fixture to test the   performance of the parts.   According   to the standard, print out such as Fm, Rm, Rp, ReH, ReL, Re, A, Z, and E, and   load-deformation, stress-strain, load-time, deformation-time,   displacement-time curves .  Suitable   for metal, rubber, plastic, spring, textile, and components testing. It is   widely used in the corresponding industries, research and development, test   institutes and training centers etc.


Technical Parameters:

Unit switching:kg、 lb、 N、 kN

Load accuracy:±1%(±0.5%)

Load resolution :0.005~1000mm/min

Test speed:0.005~1000mm/min

Speed accuracy:±1%(±0.5%)

Deformation measurement accuracy:±0.5%

Effective test space:600mm×800mm

Weight:around 1500kg~2000kg

Dimension:(W×D×H)around 1200×700×2500 mm

Power supply:3∮,AC380V/3.0kW~5.5kW
