Tensile tester servo control high temperature tester low temperature tester

Mold number : GP-TS2000L/HLTD

Product name: servo control high/low temperature tester

Servo control high/low   temperature tester  special for variety metal, Non-metallic   material ,Composite materials and them   product Mechanical properties testing and analysis . Applicable for wide   range of Aerospace,Petrochemical,vehicle,Machine manufacture industries etc   .according to GB,JIS,ASTM,DM,ISO etc standard Automatically display mix   number of test.Breaking force ,up  down   Yield Strength,tensile strength,Various Elongation stress,Compressive   strength,Bend deflection,Elastic Modulus,Poisson's ratio etc .Equipped with a   special fixture to test the performance of the parts.According to the   standard, print out such as Fm、Rm、Rp、ReH、ReL、Re、A、Z、Ae、μ and E, and   load-deformation, stress-strain, load-time, deformation-time,   displacement-time curves .  It is   widely used in the corresponding industries, research and development, test   institutes and training centers etc.

Technical Parameters:

Capacity   option：200kN、300kN、500kN、600kN
  unit switching：kg、 lb、 N、 kN
  Load accuracy：±1%（±0.5%）
  Load resolution：1/300,000
  Test speed：0.005～1000mm/min
  Speed accuracy：±1%（±0.5%）
  Deformation measurement accuracy：±0.5%
  Effective test space：600mm×800mm
  Weight：约1500kg～2000kg
  Dimension：(W×D×H) around 1200×700×2500 mm
  Power supply：3∮,AC380V/3.0kW～5.5kW
