GOPOINT High Quality Material Testing Machine Servo Control Universal Material Tester

servo control universal material tester (big change )It can test and analyze the mechanical properties of various metals, non-metals, composite materials and their products. Widely used in aerospace, petrochemical, vehicle, machinery manufacturing and other industries. The maximum test force value, breaking force value, upper and lower yield strength, tensile strength, various elongation and stress, compressive strength, bending deflection, and elasticity can be automatically obtained according to GB, JIS, ASTM, DM, ISO and other standards. Modulus, Poisson's ratio and other parameters. Equipped with special fixtures to test the performance of the parts, according to the standard, Fm, Rm, Rp, ReH, ReL, Re, A, Z, Ae, μ, E and other mechanical properties and load-deformation, stress-strain, Load-time, deformation-time, displacement-time curve. It is an ideal equipment for enterprises, supervision institutions, product testing and scientific research, and school teaching research.

Technical specifications:

Mould Number：GP-TS2000S/TSL

Capacity(optional): 1kN、2kN、5 kN、10kN、20 kN

Unit(Switchable): kg、 lb、 N、 kN、

Load Accuracy : ±0.5%

Load Resolution:1/100,000

Test Speed: 0.001～500mm/min

Speed Accuracy :±0.2%

Accuracy of  strin gauge: ±0.5%

Test space : 400×1300mm

Dimension:(mm  W×D×H) 680×450×1650

Weight:(approx) 120kg

Power :220V AC/400W～750W
