The servo-controlled high-low temperature material testing machine is widely used for tensile, compression, bending, shearing, peeling, tearing and other mechanical properties tests of metal and non-metal materials. If equipped with special fixtures, the performance of the parts can be tested. . The maximum test force value, breaking force value, upper and lower yield strength, tensile strength, various elongation stress, elongation, compressive strength, bending can be automatically determined according to GB, JIS, ASTM, DM, ISO and other standards. Deflection, elastic modulus and other parameters. Equipped with special fixtures to test the performance of the parts, according to the standard, Fm, Rm, Rp, ReH, ReL, Re, A, Z, E and other mechanical properties and load-deformation, stress-strain, load-time, Deformation - time, displacement - time and other curves. It is an ideal equipment for product testing and scientific research and school teaching research in enterprises and supervisory organizations. |
Technical specifications:
Mould number：GP-TS2000PM/HLTD
Capacity option： 10kN, 30kN, 50kN, 100kN
Unites switch to： kg, lb, N, kN
Load accuracy： ±1% (±0.5%)
Load resolution： 1/10,000 (1/100,000)
Crosshead speed ： 0.005~1000mm/min
speed accuracy： ±1% (±0.2%)
Distortion measuring accuracy： ±0.5%
Available testing speace： 560mm×800mm
Net weight ： approx.1200kg~1500kg
Volume： (W×D×H) 1000×620×2000mm
Power： 3§ AC380V/1.5kW~2kW
