Features:
1. green laser diode 50mw
2. osram laser diode PL 520
3. TO18-3.8mm package type
Osram 3.8mm High Quality Green 520nm Laser Diode
Excellent beam quality High stability Advanced technology Long Lifetime
Maximum Ratings (Tc = 25ºC)
| Parameter | Symbol | Min. | Max. | Unit |
| Operating Current | If | - | 260 | mA |
| Reverse Voltage | VR | - | 2 | V |
| Operating Temperature | Tc | +10 | +70 | ºC |
| Storage Temperature | Tstg | -40 | +85 | ºC |
| Soldering Temperature max. 10 sec. | Tsolder | - | 260 | ºC |
Laser Characteristics (Tc=25°C)
| Parament | Symbol | Min. | Tye. | Max. | Unit |
| Emission Wavelength | λp | 515 |
520 | 530 |
nm |
| Optical Output Power |
Po | - |
50 | - | mw |
| Spectral Width(FWHM) | △λ | - | 2 | - | mA |
| Threshold Current | Ith | - |
60 | 120 | mA |
| Operating Current | If | - | 160 | 200 | mA |
| Operating Voltage | VF | - |
7.3 | 8.0 |
V |
| Beam Divergence(FWHM) | θ∥×θ⊥ | 4×16 | 6×22 | 11×25 | deg |
| Polarization | Pgr | 20:1 |
- |
- | |
| Modulation Frequency | f | - | >100 | - | MHz |
Description:
1. Efficient radiation source for cw and pulsed operation.
2. Single transverse mode semiconductor laser .
3. High quality Osram TO38 520nm 50mw green laser diode PL520.
4.Package details: Plastic box package, it depends on different kinds of laser diodes with different sizes.Normally 200pcs in one tray, 10 trays in one bag ,then 10 bags in one carton box.
Welcome your inquiry
TO: Ms. Elin
Mob: +86 18002689266
Dongguan BU Laser Co., Ltd
Shipping：
1.The items normally will be shipped within 3 working days after the payment is reached.Delivery time is about 3-5 days.
2.The items will be shipped by DHL/FedEx or other ways. Please contact us directly and choose the way you prefer.
Company Information&Services:
A. Main products: Semiconductor laser diode, laser module, bicycle laser light.
B. Since the establishment, DongguanBlueuniverse Laser Co., Ltd has its own brand "LANJI, VIAN", access to China's outstanding semiconductor laser supplier reputation, with a number of domestic and foreign technology patent certification, product quality inspection certification and TUV, BV, SGS, ISO9001: 2015 quality management system certification.
Warranty:
All products have been tested before the shipment and it was packaged in good condition. Please tested the products at first before you assemble it, if any problem here, please inform us within 3 days of receipt. We can arrange the replacement for you if the situation is confirmed.
