Triple Electric Flange Hard Sealing Butterfly Valve (GAD943H)
USD $2 - $50
/ Piece
10 Pieces(Min.Order)
- 1000 Piece / Pieces per Month
- Ningbo
- T/T Other
- 45 days
You May Like
-
Wafer Lug PTFE/PCTFE/FEP/PFA Lined Butterfly Valve (GAD71F)
-
Worm Gear Box Butt Welded End Metal Sealing Butterfly Valve (GA363H/F)
-
Manual Soft Seal Wafer Type Butterfly Valve (GAD371X)
-
Bellows Thermostatic Steam Trap/Liquid Expansion Type Steam Trap (GACS44H/GACS14F)
-
Adjustable Constant Temperature Type Steam Trap (GASTC)
-
FT43 Ball Float Steam Trap
Product Details
| Brand Name | goole | Place of Origin | China | |
| Model Number | GAD943H | Material | Forged | |
| Application | General | Structure | Butterfly | |
| Standard or Nonstandard | Standard | Pressure | Medium Pressure | |
| Power | Hydraulic | Port Size | Ningbo | |
| Media | Gas | Temperature of Media | Medium Temperature |
Product Description
Special Features:
Materials: stainless steel and carbide
Corrosion-resistant
Simple and compact structure
Lightweight
Easy to install or disassemble
Convenient maintenance
Easy and convenient to operate
Applicable temperature:
| Carbon | 29 to 425°C |
| Stainless steel | 40 to 650°C |
| Alloy | 29 to 800°C |
Structure and Material.
| No | Part Name | Material | ||||
| 1 | Body | ASTM A216 WCB | ASTM A351 CF8 | ASTM A351 CF3 | ASTM A351 CF8M | ASTM A351 CF3M |
| 2 | Pin | ASTMA29-1035/A276 304 | ASTM A276 304 | ASTM A276 304L | ASTM A276 316 | ASTM A276 316L |
| 3 | Stem | 420/304/316 | 304 | 304L | 316 | 316L |
| 4 | Disc | WCB/CF8/CF8M | A351 CF8 | A351 CF3 | A351 CF8M | A351 CF3M |
| 5 | Sealing ring | 304/316+Graphite/PTFE | 304+Graphite/PTFE | 304L+Graphite/PTFE | 316+Graphite/PTFE | 316+Graphite/PTFE |
| 6 | Seat | A105/A182/F304/F316 | F304 | A182 F304L | A182 F316 | A182 F316L |
| 7 | Bolt | B7/B8/B8M | B8 | B8 | B8M | B8M |
| 8 | Bolt | B7 | B8 | B8 | B8M | B8M |
| 9 | Bottom cap | A105 | A182 F304 | A182 F304L | A182 F316 | A182 F316L |
| 10 | Gaskett | Graphite | Graphite | Graphite | Graphite | Graphite |
| 11 | Bottom bushing | Luberized bronze 304 Nitriding | 304 Nitriding | 304L Nitriding | 316Nitriding | 316L Nitriding |
| 12 | Top bushing | |||||
| 13 | Packing | A105/304 | 304 | 304L | 316 | 316L |
| 14 | Packing gasket | Graphite | Graphite | Graphite | Graphite | Graphite |
| 16 | Gland | WCB | CF8 | CF3 | CF8M | CF3M |
| 17 | Nut | A194 2H | A194 8 | A194 8 | A194 8M | A194 8M |
| 18 | Bolt | A193 B7 | A193 B8 | A193 B8 | A193 B8M | A193 B8M |
| 19 | Yoke | WCB | WCB+Zn,CF8 | |||
