Home > Products > Quilting machine (computerized model) > CSDS128"-2 Hot Sale Industrial Quilting Machine
CSDS128"-2 Hot Sale Industrial Quilting Machine
- Shen Zhen Port
- T/T Money Gram
You May Like
Product Details
| Condition | New | Place of Origin | Guangdong, China | |
| Brand Name | CHISHING | Model Number | CSDS128-2 | |
| Max Sewing Speed | 500r/m | Max Sewing Thickness | ≤30mm (faom) polyester fiber :400g/m2 | |
| Number of Head | Single Head | Moving Style | Frame Moved | |
| Voltage | 380v | Power(W) | 6.2kw | |
| Dimension(L*W*H) | 5600*1200*1650mm | Weight | 4000kg | |
| Certification | CE, ISO 9001:2008 | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CSDS128"-2 digital control quilting machine
1. D: Digital control; S: Small shuttle (HQ7 Japaneseshuttle )
2.128": 128inch width (3251mm)
3.2: Two needle row
4. Overall dimentions: 5500*1100*1600mm
5: Weight: 4000kg
6: Running speed: 200-500r/m
7: Needle distance: 25.4mm
8. Rating power: 6.2kw
9. Thickness: ≤30mm
10. Max. Pattern size: 6inch by 6inch
Technical Specification:
Model | CS64-2 | CS64-3 | CS94-2 | CS94-3 | CS110-2 | CS110-3 | CS128-2 | CS128-3 |
L Dimensions W H | 3600mm | 3600mm | 4600mm | 4700mm | 5200mm | 5300mm | 5500mm | 5600mm |
1100mm | 1200mm | 1100mm | 1200mm | 1100mm | 1200mm | 1100mm | 1200mm | |
1600mm | 1650mm | 1650mm | 1650mm | 1600mm | 1650mm | 1600mm | 1650mm | |
Quilting Width | 64inch | 64inch | 94inch | 94inch | 110inch | 110inch | 128inch | 128inch |
Max. Needles’ Quantity | 128 pcs | 192 pcs | 188 pcs | 282 pcs | 220 pcs | 330 pcs | 256 pcs | 384 pcs |
Pattern size | 1-6inch | 1-12inch | 1-6inch | 1-12inch | 1-6inch | 1-12inch | 1-6inch | 1-12inch |
Needle Distance | 1 inch | 1 inch | 1 inch | 1 inch | 1 inch | 1 inch | 1 inch | 1 inch |
X-driver | 8 inch | 12 inch | 8 inch | 12 inch | 8inch | 12inch | 8inch | 12inch |
Quilting Thickness | ≤30mm | ≤30mm | ≤30mm | ≤30mm | ≤30mm | ≤30mm | ≤30mm | ≤30mm |
Needle Stitch | 2-6mm | 2-6mm | 2-6mm | 2-6mm | 2-6mm | 2-6mm | 2-6mm | 2-6mm |
Needle Model | #16,#19 | #16,#19 | #16,#19 | #16,#19 | #16,#19 | #16,#19 | #16,#19 | #16,#19 |
Running Rate | 200-500r/m | 200-500r/m | 200-500r/m | 200-500r/m | 200-500r/m | 200-500r/m | 200-500r/m | 200-500r/m |
Production Capacity | 2-120m/h | 2-120m/h | 2-120m/h | 2-120m/h | 2-120m/h | 2-120m/h | 2-120m/h | 2-120m/h |
Voltage | 3.5kw | 3.5kw | 3.5kw | 3.5kw | 6.2kw | 6.2kw | 6.2kw | 6.2kw |
Weight | 2300kg | 2600kg | 3000kg | 3400kg | 3500kg | 3800kg | 4000kg | 4500kg |
Applications:
This kind of quilting machinery adopt digital control program. It is widely used for quilting high-quality bedding covers ,quilt covers, garments, handbags, sofa and mattress protectors, seat-covers, kitchen sets(aprons, oven glovers, potholders) and household ornaments. Different patterns are available.
*This quilting machine Adopting digital control program.
*Saddles and rollers driven by Panasonic servo devices.
*The revolution of the spindle controlled by panasonic frequency conversion control devices.
*Large number of built-in quilting patterns for your choice.
*Easy and quick make new designs.
*360 degrees quilting
*Tack and jump function included
*stitches between 2mm-6mm adjustable.
*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
*Simulation display of quilting.
*Automatic needle raising and location brake system.
*Function of automatic stop on breaking of thread(optional)
*Infrared sensors to guarantee the safety of the operator
NOTE:Machines of non-standard specifications can also be nanufactured by order of customers with specific requirements.
