Shuttle Multi Needle Bedding Covers Machine Quilting (cs64)

Shuttle Multi Needle Bedding Covers Machine Quilting (cs64) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
chishing
Model Number:
CS64
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name chishing
Model Number CS64
Max Sewing Speed 1600mm
Max Sewing Thickness 400g/m2
Number of Head Other
Moving Style Other
Voltage 380v
Power(W) 3.5kw
Dimension(L*W*H) 3800*1200*1650mm
Weight 2600kg
Certification ce
Warranty 1
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Imported materials , high accuracy and lifetime service.
infare protection and high security.

>The multi needle quilting machine Adopting digital control program.
>Saddles and rollers driven by Panasonic servo devices.
>The revolution of the spindle controlled by Panasonic frequency conversion control devices.
>360 degrees quilting, Machine come with 300 quilting patterns for your choice

>Easy pattern drawing system enable you finish the pattern design in a few minutes.

>Tack and jump function included
>stitches length 2mm-6mm adjustable.

>Pattern compensation

>Adjustable pressing plate lifting mechanism enables you quilt a broad range of material thickness.
>Simulation display of quilting.

>Thread break detectors.

>Automatic needle raising and location brake system.

>Error problem detection system.

> Emergency sensors safety device

>Improved quilting software control system allows more precise and stable quilting operations.

>Improved fabric loading system :The fabric-loading motor provides tension control and ensure the quilting effect .

 TECHNICAL DATA

      Max.needles   Quilting RUNNING  NEEDLE RATING    NEEDLE  QUILTING
SPECIFICIATION Size ( L*W*H)  WEIGHT quantity STROKE width RATE DISTANCE POWER VOLTAGE MODEL THICKNESS
CS64INCH 2NEEDLE ROW 3600*1100*1650mm 2300KG 128pcs 203.2mm 1626mm 200-500R/M 25.4mm 3.5kw 380V 16/19 ≤30mm
≤400g/m2
CS64INCH 3NEEDLE ROW 3800*1200*1650mm 2600KG 192pcs 304.8mm 1626mm 200-500R/M 25.4mm 3.5kw 380V 16/19 ≤30mm
≤400g/m2



Application:bedding covers processing ;garments processing ,handbags processing and sofa protectors processing
